| Item | Specifications | |
| 1 | Image Sensor | 1/2.8 inch CMOS sensor |
| 2 | Effective Pixel | 5 Mage Pixel (2K) or above |
| 3 | Video Resolution | 2592x1944 /30FPS |
| 4 | lens zoom | 10 x optical zoom |
| 5 | focal length | f=4.7 - 47±5%mm |
| 6 | horizontal view angle | 70.9° |
| 7 | minimum illumination | 0.2 Lux (F1.2) |
| 8 | audio focus/location | According to the direction of the sound, the camera rotates automatically to find the sound source and accurately focus on it to ensure that the speaker appears in the picture all the time. |
| 9 | Focus Mode | Auto focus |
| 10 | white balance | Auto |
| 11 | Wide Dynamic (WDR) | Support |
| 12 | Three application mode | 1.local conference mode：340°,audio focus/location。 conference mode：180°, audio focus/location。 3.manual mode：IR Remote Controller control and adjust the rotation. |
| 13 | Communication baud rate | 115200 |
| 14 | Pan/ Horizontal rotation | 0 - 340° |
| 15 | Tilt/ Vertical rotation | 0 -180° |
| 16 | Pan/ Horizontal rotation speed | 0 - 30°/second |
| 17 | pitching movement speed | 0 - 23.5°/second |
| 18 | Preset position | Support |
| 19 | Microphone array | 4 Microphones array |
| 20 | Microphone type | Digital silicon label |
| 21 | Sampling frequency /Use digits | 48KHz/24bit |
| 22 | Sensitivity | -29dB |
| 23 | Pickup Distance | 6 meters |
| 24 | Horizontal radio pickup Angle | Horizontal 360° |
| 25 | SNR (Signal to Noise Ratio) | 65dB |
| 26 | Power Consumption | 6W |
| 27 | Mute | Support |
| 28 | Driver Free USB | Support |
| 29 | Operation System | Support Android，Iphone, windows System |
| 30 | IR Remote Controller | Support |
| 31 | serial communication control | Support |
| 32 | Software Upgrading | Support |
