Product Attributes
|
|
|
P/N
| WTL2.07142ZX
|
|
|
Series
| TX3
| 10^24
| 24^104
|
Size / Dimension
| 3.2x2.5 mm
|
|
|
Frequency
| 16.000MHz
|
|
|
Load Capacitance(CL)
| 9pF
|
|
|
Frequency Tolerance (at 25°C)
| ± 10ppm
|
|
|
Frequency Stability Over Operating
Temperature Characteristics
| ± 20ppm
|
|
|
Operating Temperature Range
| -20°C--+70°C
| 80Ω
| 60Ω
|
Operating Mode
| Fundamental
|
|
|
Package / Case
| 4-SMD, No Lead
|
|
|
Packaging
| Tape & Reel (TR)
|
|
|
Storage Temperature Range
| -55 °C to + 125 °C
|
|
|
Shunt Capacitance (C0)
| 5.0 pF Max
|
|
|
Driver Level
| 10µW~100µW
|
|
|
Equivalent Series Resistance ESR
| 60Ω Max
|
|
|
Aging @25°C 1st year (Max)
| ± 3ppm/year
|
|
|
Shock Resistance
| Drop test of 3 times on 2mm stainless plate from 75cm height
|
|
|
