| Specification | Unit | SUHM260 |
| Table size | mm (in) | 1120X260 (44″x 10″) |
| T slot(width×num×spaces) | nos/mm | 14 x 3 x 63 |
| Max. load of Table | kg | 250 |
| Longitudinal travel of Axis X | mm | 600 (24″) |
| Cross travel of Axis Y | mm | 270 (10″) |
| Vertical travel of Axis Z | mm | 380 (15″) |
| Spindle taper | ISO40 | |
| Spindle speed/step-Vertical | rpm | 45-1660/11 steps |
| Max.end milling width | mm | 125 (5″) |
| Max. vertical milling Dia. | mm | 25 (1″) |
| Swivel angle of swivel head | degree | 360º |
| Distance from vertical spindle axis to column surface | mm | 60-500 (2″-20″) |
| Distance from vertical spindle nose to table surface | mm | 100-480 (4″-19″) |
| Arm travel | mm | 440 (17″) |
| Feed speed of Axis X/Y (Longitudinal/cross) | mm / min | 24-402/9 steps |
| Feed speed and step of Axis Z (Vertical) | mm/min | 422/1step |
| Rapid Traverse of AxisX/Y (Longitudinal/cross) | mm / min | 402 |
| Rapid Traverse of Axis Z (Vertical) | mm/min | 422/1step |
| Main motor | kw | 2.2 |
| (X/Y/Z) Feed motor | kw | 0.37(X/Y),0.55(Z) |
| Coolant motor | kw | 0.04 |
| Overall dimension | mm (in) | 1660x1500x1730 65″x59″x68″ |
| N/WG/W | kg | 1480/1680 |
