EI33 gate drive transformer

Product Details

Product Description

Product Description
EI33 gate drive transformer
1. Working frequence：10kHz-500KHz
2. Output power：0.5 to 90 W
3. Working temperature：-40℃ to +125℃
4. Storage temperature：-25℃ to +85℃
5. Storage humidity：30 to 95%
High frequency transformer is a kind of electronic transformer which work frequency exceed 10kHz, it widely used in switch power supply, inverter power supply, power meters, Telecom, and inverter welding machine, etc. High frequency transformer as the most important parts in switch power supply, there are so many topological structure, such as full/half Bridge structure. Not only could manufacture bridge transformer, we also have flyback transformer.

Type	Structure	Dimension（mm）			Pin Row（mm）		Row Pitch(mm)	OD Pin（mm）	Note
		A	B	C	Pin	E	F
EI33-001	Vertical	35	30	32.5	6+6	5	22.5	Φ0.8
EI33-002	Vertical	36	30	32.5	7+7	5	22.5	Φ0.8
EI33-003	Vertical	40	30	32.5	8+8	5	22.5	Φ0.8
EI33-004	Vertical	45	30	32.5	9+9	5	22.5	Φ0.8
EI33-005	Vertical	48	32	32.5	17+17	2.54	20.5	Φ0.7
EI33-006	Vertical	48	32	31.5	18+18	2.54	23	Φ0.7

Customized products are available.
EI33 gate drive transformer is the power transformer whose working frequency exceeds the medium frequency (10 kHz). It is mainly used in switching power supply, inverter and solar system. According to the working frequency, it can be divided into several grades: 10khz-50khz, 50khz-100khz, 100kHz ~ 500kHz, 500kHz ~ 1MHz, 10MHz or above.

---
