| LCD screen size | 7” |
| Resolution | 800*480 |
| Contract | 500:1 |
| Brightness | 400 cd/M |
| Viewing Angle | U:50/D:70,R/L:70 |
| Dot Pitch | 0.0642(W)*0.1790(H) |
| Aspect Ratio | 16:9 |
| Channel | 1 to 4 channels |
| Operating Frequency | 2400-2483.5MHZ |
| Receiving Sensitivity | -89 dBm |
| Decompression Form | MPEG4 |
| Transmit Output Power | 17dBm |
| Modulation | 2.4G FSK/GFSK |
| Time Delay | 120ms |
| Transmitting Distance | 30-120M |
| Micro-SD/TF Card | Max. 128GB |
| System Format | PAL/NTSC |
| Power Supply | DC 9~36V |
| Power Consumption | Max. 6W |
| Loudspeaker | 1.5W/8Ω |
| Operating Temperature | |
| Storage Temperature |
