Product Details
Product Description
Product Description
Product Description
PET flake Washing Line is used to wash and recycle pet bottle We can supply production line with capacity from 200kg/h to 3000kg/h.
We can design different recycling line for you according to your request:
1) parallel bale opener can process the PET bottle packages from 100~600kg, more safety
2) roller sorting machine: separate the impurities out from the PET bottles, such as metal, sand, etc.
3) label removing system: use the gearshape blades to peel off the labels from the bottles body, removing ratio>98%
4) sorting table: detect metal automatically for crusher protection, and separate the PVC bottles out manually after a UV-detect device.
5) Crusher: the bladesquality is good, wearable and long life.
6) Screw feeder: spiral convey and wash the PET flakes by the friction force in the special structure.
7) friction washing machine: three friction force here for washing during the high speed rotating: rotor and flakes, steel sieve with flakes, flakes and flakes.
8) Float washing tank: keep washing the materials continuously, subside the PET flakes, float and push out the labels,caps and rings.
9) Dewatering machine: dewater the flakes by the rotor with high rotary speed, humidity ratio<2%
10) Drying system: adopt electricity heating and blower for drying the flakes, humidity ratio<1%
Main Features
Plastic recycle machine is widely used to treat PET bottle (coke bottles) and scrap PET plastic broken into flakes.
It is a crushing, washing, drying line. PET flakes are mainly used for the fiber production and other related PET products.
This production line is high automatic operating and save labor cost and low after maintenance.
With advanced international industry concepts and technologies to meet waste plastic recycling at home or abroad.
Detailed Images
PET bottle washing&recycling line of Technical Parameters
Input capacity
| 500kg/h
| 1000 kg/h
| 2000 kg/h
|
Workshop(M*M*M)
| 42 (L)×10(W)×6(H)
| 55(L)×15(W)×6(H)
| 70(L)×18(W)×6(H)
|
Ancillary staff
| 6Persons
| 8 Persons
| 12 Persons
|
Installation power
| 156KW
| 307KW
| 420KW
|
Water Consumption:
| 2Ton/h
| 3.5Ton/h
| 5 Ton/h
|
Final product
| Moisture: max 1%
Bulk density: 0.3G/CM3
Particle size: 14-18mm
Metal content: max.20ppm
Floatable contamination: less than 200ppm
Total impurity: 320ppm
| Moisture: max 1%
Bulk density: 0.3G/CM3
Particle size: 14-18mm
Metal content: max. 20oom
Floatable contamination: less than 200ppm
Total impurity: 320ppm
| Moisture: max 1%
Bulk density: 0.3G/CM3
Particle size: 14-18mm
Metal content: Max. 20ppm
Floatable contamination: less than 200ppm
Total impurity: 320ppm
|
Finished product
Factory spot goods
In-sale:
• Detailed design of lay-out that is the position of the procession
• Technological information of provided products
• Schedule about design,manufacturing and installation
• Working & Producing progression
• Training course for the technician so that the installation is safe and standard
After-sale:
• For customers buying our products, we provide them free training so that they can use and maintain the machine independently.
• We will answer customer's question on technology in time. If needed, we will offer on-site guidance and assistance.
• We can provide free technical guidance if customers need new equipment, add or rebuild equipme
Packing & Delivery
Certifications
Bank slip
