Oil Country Lathe Q1327, Big Bore Lathe with Double Chuck

Product Description

Product description:
Technical parameter :
Technical parameter :

Specifications		UNIT	Q1327
Capacity	Swing over bed	mm	1000
	Swing over cross slide	mm	610
	Distance between centers	mm	1500/3000
	Pipe threading range	mm	Ø130-270
	Width of bed way	mm	755
	Max.load capacity	T	5
Spindle	Spindle bore	mm	Ø280
	Spindle speed steps	-	12 steps
	Spindle speed range	rpm	16-380
	Chuck size	mm	800
	Chuck type	-	4-jaw manual
Turret	Turret type	-	Manual 4 position
	Tool shank size	mm	40x40
	Turret travel	mm	300
Carriage	X axis feed grade/range	mm/r	64/0.05-12.15
	Z axis feed grade/range	mm/r	64/0.1-24.3
	X axis rapid traverse speed	mm/min	1870
	Z axis rapid traverse speed	mm/min	3740
	X axis travel	mm	520
	Z axis travel	mm	1310/2810
Tailstock	Tailstock quill diameter	mm	140
	Tailstock quill taper	-	MT6
	Tailstock quill travel	mm	300
Motors	Main spindle motor	kW	22
	Rapid traverse motor	kW	1.5
	Coolant pump motor	kW	0.125
Thread	Metric thread grade/range	mm	30/1-30
	Inch thread grade/range	T.P.I.	27/1-28
Dimensions	Width x Height	mm	2100X1600
	Length	mm	4190/5690
Weight	N.W./G.W.	T	10.0/11.5

Standard accessories:
3-jaw chucks,
Tapper turning attachment,
Work lamp,
Coolant pump,
Rear support bracket,
Optional accessories:
Digital readout,
Bigger size chuck,
Face plate,
Thread chasing dial,
Steady rest,
Follow rest
Protective cover
Grinding attachment etc. Company information:
FAQ
Q: Are you a trading company or a physical factory?
A: We are a specialized physical factory for more than 10 years. Our machines also gained CE certificate, ISO9001 and EAC certificate.
Q: What's your main products of your company?
A : We specialized in Vertical Machining Center, CNC Lathe, Milling Machines, Lathes, Drilling Machines, Saws, Shapers and so on.

Q: Can you provide customized machine?
A: Yes, we provide customized service for customers to meet different requirements.


Q: Can we visit your factory?
A: Sure, we warmly welcome you to visit our factory at any time. The more you know about us, the more you will trust us! So you can rest assured on our quality machines and our best service.
Q: What's the Payment Terms ?
A : T/T ,30% deposit when order ,70% balance payment before shipment ; Irrevocable LC at sight.
Q: What is your trade terms?
A: FOB, CIF ,DDP and CFR all acceptable.

---
