High Precision Rd-Vl7075 Single Spindle Flatbed Automatic Heavy Duty Metal CNC Vertical Lathe Machine

US$20,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
RD-VL7075
Type
Vertical Lathe
Processing Accessory
Centre CNC Lathe
Guide Rail
Horizontal Guide Rail
Tool Holder
Single-tool Holder CNC Lathe
Power Source
Electric
Controlling Mode
CNC
Automatic Grade
Automatic
Setting Mode
Floor-type
Precision
High Precision
Condition
New
Max. Swing Diameter
750
Max. Turning Diameter
700
Max. Turning Height
750
Spindle Speed
50-1500
Max. Spindle Torque
770
Transport Package
Wooden Case
Origin
China
Production Capacity
100

Product Description

ITEM UNIT RD-VL7075 RD-VL8090 RD-VL1000
Max. swing diameter mm 750 900 1100
Max. turning diameter mm 700 800 1000
Max. turning height mm 750 750 900
Spindle nose A2-11 A2-11 A2-11
Spindle speed r/min 50~1500 50~1500 50~1000
Chuck diameter in 15 18 21
Max. spindle torque N.m 770 770 1200
Max. loading capacity kg 1000 1000 1000
Spindle motor power kw 22 22 22
CNC system FANUC/SIEMENS/KND/GSK FANUC/SIEMENS/KND/GSK FANUC/SIEMENS/KND/GSK
2 axis guide rail SRG45LR Extended slider SRG45LR Extended slider three-rail SRG55LR Extended slider
2 axis lead screw DIK5210 DIK5210 DIK5210
X/Z axis motor power kw 2.8/3.6 2.8/3.6 2.8/3.6
X/Z axis fast move speed m/min 20 20 20
X axis travel mm -50~+750 -50~+850 -50~+1100
Z axis travel mm 700 700 800
X/Z axis positioning accuracy mm ±0.005 ±0.005 ±0.005
X/Z axis repeated positioning accuracy mm ±0.003 ±0.003 ±0.003
Turret tool number 10/12 10/12 5/6
Tool size O.D tool/Boring tool mm 32x32/50 32x32/50 32x32/50
Hydraulic control range MPa 0.1-6 0.1-6 0.1-6
Machining precision IT6~IT7 IT6~IT7 IT6~IT7
Surface roughness Ra1.6 Ra1.6 Ra1.6
Stampings pump head/flow 34m/4m³/h 34m/4m³/h 34m/4m³/h
Cooling pump head/flow 28m/4m³/h 28m/4m³/h 28m/4m³/h
Chip conveyor Chain chip removal Chain chip removal Chain chip removal
Working voltage Hz 380V±10% 50Hz 380V±10% 50Hz 380V±10% 50Hz
Machine electrical capacity kVA 35 40 40
Dimension mm 1800x3100x3100 2200x3200x3100 2300x3600x3500
Machine tool protection Full protection Full protection Full protection
Weight kg 9000 10000 12500
