HC-C021C Portable Handheld Ultrasonic incentive Spirometer with a cheap price / Pulmonary Function test

Product Description

Product Description
HC-C021C Portable Handheld Ultrasonic incentive Spirometer with a cheap price / Pulmonary Function test
Product Description
Features for HC-C021C Portable Handheld Ultrasonic incentive Spirometer with a cheap price / Pulmonary Function test:
Introduction:
Handheld Pulmonary Function Spirometer adopts ultrasonic technology by ultrasonic gas flow sensor to measure body’s respiratory function and inspiratory function, to convert the patient breathing signal into electrical signal which is sent to corresponding signal processing circuit, to display real-time respiratory flow curve and then to calculate a variety of physiological and spirometric parameters. It can be used to monitor static vital capacity, forced vital capacity and maximum voluntary ventilation rate. The software can automatically do BTPS correction and evaluate pulmonary function.
Specifications:
Measure exhale and inhale function of the human body
Portable and compatible
No need to replace the sensor, no maintenance, simple, light-weight, easy handling
Dedicated disposable mouthpiece, suitable for children and adults
Upgradable and expandable

Working conditions
Ambient temperature		5℃-40℃
Relative Humidity		≤95% RH (non-condensing )
Atmosphere pressure		80kPa-106kPa
Power supply		DC 4.75V-5.25V (supplied via USB port)
Items	Ranges		Max error
VC (Vital Capacity)	(0.5-8)L		±3% or ±0.050L whichever is larger
FVC(Forced Vital Capacity)	(0.5-8)L		±3% or ±0.050L whichever is larger
MVV(Maximum Ventilatory Volume)	250L/min		±3% or ±15L/min whichever is larger
Configurations
Handheld Pulmonary Function Tester * 1 unit				Setup CD disc * 1 pc
Breather pipe * 10 pcs				USB softdog * 1 unit
nasal splint * 10 pcs				Trolley and braket * 1 set
Mouthpiece (consumable) * 10 pcs				Personal computer * 1unit (optional)
Users Manual * 1 pc				Printer * 1 unit (optional)

Application:
Test instruments used in respiratory internal medicine, pulmonary medicine, tracheitis medicine, surgery etc.
Preoperative Pulmonary function tests.
With the needs of the internal medicine diagnosis and treatment.
The physical examination of the company and the school.
To meet the needs of industrial hygiene.
To meet the needs of the cardiology medical work.
Pictures for HC-C021C Portable Handheld Ultrasonic incentive Spirometer with a cheap price / Pulmonary Function test:
3. Installation of hand-held part is completed after the above two steps, and then connect the
USB on the handheld part to the computer's USB port, to make it in test ready condition.
Run software:
Configuration:
Calibration:
Select Patient:
Packaging & Shipping
Company Information
Our Services
Contact
FAQ
1. How to place order of HC-C021C Portable Handheld Ultrasonic incentive Spirometer with a cheap price / Pulmonary Function test?
A: Firstly we confirm product details and then send the Proforma Invoice,
You make payment to us through Alibaba Trade Assurance or T/T, Western Union or MoneyGram,
after we confirm your payment then ship the product to you once finished production.
2. For HC-C021C Portable Handheld Ultrasonic incentive Spirometer with a cheap price / Pulmonary Function test product, What’s the minimum order quantity (MOQ)?
A: For disposable material,We have our own MOQ,For our HC-C021C Portable Handheld Ultrasonic incentive Spirometer with a cheap price / Pulmonary Function test, our MOQ:1pc,
3. What is your warranty?
A: For most products the warranty is for 12 months, some products we provide 18 months warranty.
For HC-C021C Portable Handheld Ultrasonic incentive Spirometer with a cheap price / Pulmonary Function test we provide 12 months warranty.
4. What’s your delivery time?
A: Generally it is 5 working days if goods in stock. within 10 working days if the goods need production,
And also the delivery time depands on quantity. For HC-C021C Portable Handheld Ultrasonic incentive Spirometer with a cheap price / Pulmonary Function test, the delivery time is 10 working days .
5. How to ship the product?
A: The shipping way normally depand on your quantity,total CBM and weight.
We have our own shipping company to provide best shipping cost and efficient way.

---
