Basic Info.
Certificate
CE/Mdr Udi Code
Color
Red /Blue/Light Blue
Battery Kind
Lead Acid Batteries or Lithium Batteries
Optional Upgrade 1
Import Motor
Optional Upgrade 2
Import Controller
Optional Upgrade 3
Lithium Batteries 12ah,20ah,30ah
Optional Upgrade 4
Super Seat
Optional Upgrade 5
Four Wheel Shock Absorbers
Optional Upgrade 6
Detachable Rear Body
Transport Package
Best Pearl Sponge Box+Wrapping Film
Specification
1005*590*930mm
Production Capacity
5000/Month
Product Description
Product Parameters
| Overall Size: | 110*52*95cm | Fold size: | 92*56*49cm | Battery type: | 48V/12Ah Lead-acid batteries |
| Gross / Net weight: | 51kgs / 44Kg | Seat size: | 44*34cm | Tire: | Front 8" Rear 8" Solid tire |
| Motor power: | 24V/250W Brush | Charger: | AC100~240V 1.5A 50/60Hz | Controller: | DC 18.5V-30.5V 25A MAX |
| Max driving distance: | 20 km | Ground clearance: | ≤15° | Seat Height: | 46cm |
| Speed: | 0~8km/h | Climbing capability: | ≤10° | Braking distance: | ≤3m |
| Max loading capacity: | 150 kgs | Packing size: | 107*53*58cm | Material: | Strong iron & ABS |
Product Description
Packaging & Shipping
Certifications
WHY CHOOSE US
True customer feedback
FAQ Q1: Questions about Charging?
A1: Start by turning off your wheelchair (all lamps at the joystick should be off). Use only KS MED original chargers.
After about 5-8 hours the lamp on the charger turns green and the batteries are fully charged. During charging, the charger itself becomes warm, and this is perfectly normal.
Q2: Are there any attachments available, like a tray or cup holder?
A2: Yes,our wheelchair accessories cover all the needs of users, please contact us to purchase.
Q3: Is this hard to fold up?
A3: No, you just lift feet part to the top and it folds. if you are weak, you can choose our Automatic open and fold.
Q4: Is the angle of the back adjustable?
A4: Yes, we can choose manual recliner, or choose automatic recliner, add our headres, can let you rest better. your best choose.
Q5: Must the battery be removed to fold the wheelchair?
A5: No, the wheelchair can be folded just fine when the battery is on. Its compact design hides battery when folded.
Q6: What are the tires made of?
A6: The front tires are PU solid, wear-resisting.
The back tires are inflatable, wear-resisting,we also have Rubber solid tires.
Q7: Do you offer any warranty with your wheelchairs?
A7: All of our products are supplied with a comprehensive 12 months manufacturers warranty to cover any manufacturing faults - batteries included.
Q8: Can I take a powerchair on an airplane with me?
A8: All of our powerchairs are airline friendly and we can supply all necessary specifications via email that you may need to pass onto the airline.
Q9: How Much Does A Wheelchair Weigh?
A9: KSM-601 about 25 kgs net weight, we also have lightweight 16.5 kgs for your choose.
Q10: If we have good ideas, would you like to develop them together?
A10: Of course, innovation is our eternal pursuit, which is also our advantage of customization
Welcome to our store, meeting each other is a beautiful fate
Believe me
Our wheelchairs are for personal use and for business purposes
WE ARE YOUR BEST CHOICE :) !
>>
