Automatic Laser Bridge Saw Cutter Machine

US$16,500.00-21,500.00 1 Piece (MOQ)

Basic Info.

Model NO.
GBHW-1200
Source Voltage
380V
Automation
Automatic
Cutting Ability
High Speed
Control
PLC
Certification
ISO, CE
main motor
22kw
function
cut big slab into standard sizes
Operation
Auto and easy
Key word
bridge saw machine
Transport Package
One 20′ Container Load One Machine
Specification
6300*4700*2800mm
Trademark
Great Base
Origin
China
HS Code
84641090
Production Capacity
500sets/Year

Product Description


Applications:
This machine is applicable for the cutting of granite and marble slabs, cement products, asbestos products, etc. It features a high processing precision in proper operating conditions. This machine is characterized by high precision, high performance and is particular applicable for the cutting of high-value and heavy-gauge slabs.
Features:
1.Controlled by PLC, operated expediently,accurately and stably
2.The support guide way adopts the imported linear guide way to make sure high precision and long life.
3.The main parts and components of the machine (such as frequency converter, magnetic rule, laser reticule apparatus.) are all of imported good-quality materials, thus ensuring high precision, stable performance, good adaptability as well as high reliability of the whole machine.
4.One set can be loaded in one 20 feet container.
Technical Data:
Name unit GBHW-1200 GBHW-1400
Blade diameter mm Φ1200 Φ1400
Main motor kw 22 30
Blade up/down stroke mm 700 700
Worktable size (Max. cutting size) mm 3200×2000 3200×2000
Worktable rotation angle (by hydraulic) ° 90° 90°
Max. cutting size (L*W*H) mm 3200*2000*450 3200*2000*550
Dimension (L×W×H) mm 6300×4700×2800 6300×4700×2900
Weight Kg 6500 7000
