| Model No: | ||||||||||||
| K1AS02 | K1AS04 | K1AS08 | K1AS15 | K1AS22 | K1AS30 | K1AS50 | K1BS15 | K1BS25 | K1BS35 | K1BS55 | K1BS75 | |
| 0.2KW | 0.4KW | 0.75KW | 1.5KW | 2.2KW | 3KW | 5KW | 1.8KW | 3KW | 3.8KW | 5.5KW | 7.5KW | |
| Input Power | ||||||||||||
| Control Mode | Three-phase PWM converter sine wave drive | |||||||||||
| Main Power | 220V: Single-phase/three phase 220V AC(-15~+10%,50~60Hz) | |||||||||||
| 380V: Three-phase 380V AC(-15~+10%,50~60Hz) | ||||||||||||
| Control power | 220V: Single-phase 220V AC(-15~+10%,50~60Hz) | |||||||||||
| Rated current | 220V:0.2KW/2A,0.4kW/2.8A,0.75kW/5.5A,1.5kW/10A, 2.2kW/12A,3kW/16A,5kW/25A | |||||||||||
| 380V: 1.8kW/5A,3kW/8A,3.8kW/12A,5.5kW/16A, 7.5kW/20A | ||||||||||||
| Encoder feedback | ABZ incremental encoder / absolute encoder | |||||||||||
| Environment | ||||||||||||
| Working temperature | 0~45°C | |||||||||||
| Storage temperature | -20~65°C | |||||||||||
| Working humidity | 20~85%RH or less (non-condensing) | |||||||||||
| Storage humidity | 20~85%RH or less (non-condensing) | |||||||||||
| Working and storage air | indoor (no direct sunlight), non-corrosive gases, flammable gases, oil mist, dust | |||||||||||
| Altitude | Below 1000m | |||||||||||
| Vibration | 5.8m/s² (0.6G) below 10~60Hz (Cannot be used continuously at resonant frequency) | |||||||||||
| Insulation and pressure resistance | Primary- between F and G, 1 minute under AC1500V | |||||||||||
| Functions | ||||||||||||
| IO Input | 4-channel (DC24V optocoupler isolation) Input function can be selected according to parameters below: Servo on, P action, positive rotation inhibit, negtive rotation inhibit, alarm reset,positive torque limit, negtive torque limit, error clear | |||||||||||
| IO Output | 3-channel optocoupler isolated output; the following output function can be selected according to parameters: Alarm output, position proximity, velocity consistent detection output, motor rotation detection, servo ready, torque limit, brake release | |||||||||||
| Pulse input | Differential input: 500K; open collector: 200K Pulse + direction, AB orthogonal pulse, CW+CCW pulse | |||||||||||
| Pulse output | Phase A, phase B: differential output. Phase Z: differential output or open collector output | |||||||||||
| Internal speed command | Three-speed distribution via input terminals | |||||||||||
| Overload Capacity | Max. 3 times torque | |||||||||||
| Analog input | 2-channel differential input ±10V, 1-channel single-ended 0-10V; switch according to control mode | |||||||||||
| Communication | Modbus; Customized CAN | |||||||||||
| Control modes | 12 control modes: position control, speed control, torque control, inner speed, position/speed control, position/torque control, speed/torque control, inner speed/position, inner speed/speed, inner speed/torque, speed/zero clamp, position control/command inhibit | |||||||||||
| Regenerative resistance | 400W: without external regenerative resistance; over 750W: with | |||||||||||
