200L High Shear Emulsifying Mixing Tank

Product Description

200L high shear mixing tank description
This is a 200L capacity mixing tank, MOC (material of construction) is SS304, SUS316L optional. All contact part are mirror polish without any dead angle and no pocket existing in weld joint. the mixing speed can be 36rpm, 60rpm, 80rpm, 100rpm, 200rpm or 1500rpm corless disc, or 2800rpm customized.
Main specification for the 200L mixing tank
200L & 300L stainless steel mixing tank specification

Capacity	200L	300L
FOB price	/	/
Material	SS304	SS304
Thickness of wall	3mm / 3mm / 2mm	3mm / 3mm / 2mm
Diameter	Φ800	Φ900
Height	1450mm	1650mm
Motor power	0.75 / 1.1KW	1.1 / 1.5KW
Mixing speed	36rpm	36rpm
Insulation thickness	50mm	50mm
Heating power	12~24KW	12~36KW
Heating medium	Water / steam / oil	Water / steam / oil
Cooling medium	Water	Water
Discharge pipe	DN38 (customized)	DN38 (customized)
Temperature range	30~110 degree C	30~110 degree C
Accessories:	Drainage valve Temperature gauge Oil inlet hopper Oil drainage valve	Drainage valve Temperature gauge Oil inlet hopper Oil drainage valve

200L high speed mixing tank quality
We mainly focus on high quality goods with reasonable price. We do not know how to make low quality tank. Here are some pictures for your reference. as buyer, you will get several different quotation if you offer clear reqeust on the tanks. as supplier, we suggest you compare the prices, also, we suggest you compare the quality.
Stainless steel mixing tank packing and package
For goods less than one full container, we usually use wooden package for the related tanks. For FCL goods, we usually use wrapping film to packing the tanks and then wrapping them by nylon material.
200L stainless steel mixing tank video
here is a short video of a 200L mixing tank, have a look please

https://youtu.be/i3BnyihR5vs

200L stainless steel mixing tank price
Mixing tanks are all produced based on a clear request for specific products. We all know that different product have different request on the tanks, such as mixing speed and tank material. For example, tanks for fresh milk usually use low speed mixing tank, 36rpm are common used speed, while 60 rpm may also being adopted when necessary. For washing liquid and cosmetic, the mixing speed may be 1500rpm or 2800rpm and the tank inner wall should be SS316L. it is not easy to offer a correct price for all 200L tanks. Thus, the price you see here in this web may not the final price for you. For an accurate price of this 200L tank, please get in touch with our on-line service team.

Words in the End
Your feedback is more than important to us.
Please be noted that we aim to provide exceptional service and care to every customer we work with, and we truly appreciate you taking the time to tell us about your idea on above product details.

We are ready to answer your call and questions anytime.

---
