| US$2,000.00-4,000.00 | 10 Pieces (MOQ) |
| Model | 20 |
| Opreration weight | 1490kg |
| Engine | Yanmar,Kubota |
| Power | 10.3kw |
| Bucket capacity | 0.05CBM |
| Rotation speed | 9r/Min |
| Overall dimension | 3250mmX1100mmX2300mm |
| Crawler grounding length | 1300mm |
| Crawler weidth | 180mm |
| Max digging height | 3200mm |
| Max discharge height | 2300mm |
| Max digging depth | 2200mm |
| Max digging radius | 3360mm |
| Mini turning radius | 1350mm |
| Platform clearance to ground | 370mm |
| Swing angle | 360° |
| Climbing gradient | 30° |
| Bulldozer Max depth | 190mm |
| Bulldozer Max raising height | 260mm |
| Walking speed | 0-3km/h |
| Bucket digging force | 16.5KN |
| Hydraulic system press | 160MPa |
| Bucket width | 430mm |
| Remark | Simple shed,can add cab |
| Base plate | The chassis design of small excavators is relatively compact, and most of them use track type or tire type. Tracked chassis can provide better stability and traction, suitable for a variety of complex terrain, such as muddy work sites, soft soil, etc. The wheeled chassis has higher maneuverability and moves faster on flatter roads, making it suitable for short-distance transfers in environments such as urban roads. |
| Working device | The structural strength of the boom and bucket rod can meet the needs of small excavation tasks. The hydraulic system can precisely control the action of the working device to achieve flexible digging Angle and depth. For example, when digging a pipe, the operator can control the hydraulic system so that the bucket can dig at the right Angle to avoid damaging the underground pipe. |
| Buckets are also available in a variety of shapes and sizes. There are sharp-toothed buckets for digging hard soil, and flat-mouth buckets for loading loose materials. | |
| Cab | The cab design of small excavators pays attention to comfort and operability. Although the interior space is relatively small, the layout is reasonable, and the seats can be adjusted to facilitate the use of operators of different sizes. The ergonomic placement of the handle and instrument panel allows the operator to easily operate a variety of control buttons and joysticks. The cab of some high-end small excavators is also equipped with air conditioning, radio and other equipment to improve the working comfort of the operator. |
| Driven by the development of agricultural modernization | In the agricultural field, small excavators can be used to dig irrigation ditches, clean up farm debris, dig fertilizer pits and other operations, which help improve agricultural production efficiency. With the advancement of agricultural modernization, the trend of rural land transfer and large-scale management is becoming more and more obvious, and the demand for agricultural machinery and equipment such as small excavators will also increase accordingly. For example, in some large vegetable planting bases, orchards, etc., small excavators can better adapt to the complex farmland environment and complete various earthmoving operations |
| Overseas market expansion | The demand for small excavators in the foreign market has shown a steady increase. In developed countries such as Europe and the United States, the maintenance and transformation of infrastructure, small engineering and landscape projects are increasing, and small excavators can meet the construction needs of these projects with their small and flexible characteristics. In addition, in some developing countries, with the development of the economy and the promotion of infrastructure construction, the demand for small excavators is also rising. |
| Intelligent trend | With the progress of science and technology, small excavators are developing in the direction of intelligence. For example, it is equipped with advanced sensors and control systems to achieve automatic control, remote monitoring, fault diagnosis and other functions to improve construction efficiency and safety. Intelligent small excavators can better adapt to the complex and changing working environment, meet the needs of different users, and enhance the competitiveness of products |
| Product performance improvement | Manufacturers are constantly committed to improving the performance of small excavators, such as improving digging force, improving work efficiency, and optimizing operation comfort. Through the use of new materials, new processes and new design concepts, small excavators have more powerful operating capabilities while remaining small and flexible, and can better meet the construction needs of users in various working conditions |
| 1. How long is the delivery time? According to your size and system, the delivery time is usually 15-60days. 2. Can you supply sample? Small parts can be supplied, but you should pay the express cost. 3. Can your company supply design? Our company can give g design according to your land and plan after deposit. And we can give simple drawing before signing contract. 4. How to install ? Firstly we prepare the material and send the material to your city. After your customs clearing, we send 2-4 engineers or all workers to guide to install. If you want to save money, we only send engineers, and you match local workers. If you think it is hard to build the greenhouse, we also can send engineers and workers to install for you. 5. When installing, what cost should we pay? Our engineers and workers visas and round-trip tickets, their foods and accommodation, their communication |
