Horizontal High Quality Plastic Famous Brand Multiple Repurchase Injection Machine with

US$10,000.00-400,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
U/680C
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008, CQC
Servo System
Energy Conservation
Transport Package
Ningbo Beilun Allway Machinery Co., Ltd. Belong to
Specification
CE, SGS, ISO9001: 2008, CQC
Trademark
ALLWAY
Origin
Ningbo China
HS Code
8477101090
Production Capacity
500 PCS/Year

Product Description

680 Ton High Efficiency Energy Saving Injection Molding Machine (AL-UJ/680C)
Some of the important features:

Clamping system: Faster response, stable and high rigidity

Injection system: Accurate and flexible, lower rejection rate

Control system: Computer and simple operation,molding data memory system

Power system: Energy saving, high efficient and precise

Metal parts: The thickness of our frame, metal plate and wallboard are thicker than other company.


Other Information

Show High Precision: The accurate injection positioning,pressure, speed and pressure maintaining,to ensure the repeatability error of injection accuracy less than 0.3% to achieve precision molding.

Super EnergySaving Features: Compared with standard injection machine,the energy saving rate can reach 40%-70% for the same plastic production.

High Efficiency: Compared with standard machine,the total efficiency can increase by 10% and dragging capacity is can increase by18%.

High Response System:The system acceleration and deceleration performance is quite agile and force&speed regulation is very sensitive.The sampling processing speed can reach 100KHZ and system quick start time can reach 0.05s.

Maintain Stability and Reliability:The pressure or speed is stable and switch of pressure maintaining is smooth and accurate.

Low Oil Temperature:Avoid high pressure unloading and low oil temperature situation during operation.Improve the operation performance.promote using efficiency and save a large quantity of cooling water.
INTERNATIONAL CLASS NO 680/4680
U STYLE SPECIFICATION U/680C
Screw type Unit A B C D
Injection Unit
Screw diameter mm 90 95 100 105
Screw L/D ratio L/D 23.2 22 20.9 19.9
Shot volume(therretical) cm 3 2544 2835 3140 3461
Injection weight(PS) g 2315 2580 2858 3149
Injection rate g/s 552 612 679 748
Injection pressure M Pa 184 165 149 130
Screw speed rpm 150
Clamping unit
Clamping force KN 6800
Open stroke mm 900
Space between tie-bars(WxH) mm x mm 895x895
Max mould height mm 900
Min mould height mm 350
Ejector stroke mm 250
Ejector force KN 150
Others
Max pump pressure M Pa 16
Servo system power KW 37+37
Heating power KW 42.95
Numbers of heating area 5+1
Machine demension(LxWxH) m 10.60x2.28x2.89
Oil tank cubage L 1100
Machine weight t 30.8
Remarks:The company reserves the right to modify the specification parameters without notice.
