Kbpc1010 Bridge Rectifier 10 AMP Single Phase Bridge Rectifier

Product Description

Product Description Miniature universal dimensions, welding technique
under the protection of vacuum and hydrogen gas
Glass passivated diode chips
Excellent force and volume ratio
High thermal conductive sealing package
Typical Applications
Rectifier current
Industrial automatic control
Digital-controlled machine and remte control system

Product Parameters

Diode Bridgespecifications		KBPC1010
Output current	lo	10A
Max repetitive peak reverse blocking voltage	VRRM	1000 V
RMS reverse voltage	VR(RMS)	-
Non-repetitive surgecurrent	IFSM	180 A
Safety factor	I2t	135 A²·s
Forward voltage per diode	VFM	1.1V
Forward current per diode	IFM	5.0A
Typical junction capacitance	Gj	-
RMS isolation voltage	VisoL	-
Thermal resistance,junction to case	Rth(j-c)	-
Temperature of p-n junction	Tvj max	-55 to+150ºC
Wiring diagram (circuit diagram)		four diodes

Application DC power supply for instruments and equipment
Input for PWM inverter
DC power supply for battery charging
DC motor excitation power supply
Input rectification for switching power supplies
Electrical drag and auxiliary currents
Soft-start capacitor charging, inverter fluxing
Detailed Photos

Company Profile
Zhejiang Lingshine Electric Co., Ltd (Aigoodele), is a high-tech enterprise integrating production, sales and service. Our main products are frequency converter (VFD), soft starter (LSRQ), solid state relay (SSR), solid state voltage regulator (LSCR), high power rectifiers and so on (KP, ZP, MTC, MDS, MDQ, MDC, MDK, ETC). These products have been widely used in energy, petroleum, metallurgy, chemical industry, construction, plastics, textile, water supply, paper making, mining, printing and many other industrial fields. In addition, our products not only perform well in the domestic market, but have also been exported to dozens of countries and regions in Asia, Africa, Europe and other continents, winning wide international recognition.
We look forward to cooperating with every customer, welcome your guidance and suggestions, and work together to create a more brilliant future.
FAQ Q1.Can you provide price sheet and catalog to me ?We are pleasure to provide these to you for reference,you can cotact me,give me your emails ID.
Q2.Can I get some samples?
Yes,Sample order is available for quality check and market test .but you need to pay the sample fee and shipping cost
Q3.How long is your lead time?2-3 days for the stocks items, mass production generally needed 1-2 weeks.
Q4.What's your payment terms?
We usually accept all kinds of payment terms.Such as T/T,L/C,Western Union.Cash.
Q5.What's your warranty terms?
We offer 12 months warranty time.
Q6.Do you have the products in stock?
Depends on your request,We have standard models in stock.Some special products and big order will be newly produced according to your order.
Q7 How about your payment and shipment?Payment: We accept T/T, Western Union, Paypal, Cash etc.We usually ship via DHL, UPS, FedEx or TNT, SF for small order and via ocean for bulk order according to your requirement.
Q8.How does your factory do the quality control?
Quality is priority,we always attach the importance to quality control from the beginning to the end of the production.every product will be fully assembled and carefully tested before packing and shipping.

---
