| Bodywork |
| Frame | Aluminium alloy chassis super antirust (Guarantee normal use for 10 years) |
| Body | High-strength and impact resistant composite material injected |
| Body Color | white,green,red |
| Bodywork parameters |
| Overall length: | 3150mm |
| Overall width | 1300mm |
| Overall height (with suntop) | 2150mm |
| Wheel base | 1700mm |
| Front wheel tread | 985mm |
| Rear wheel tread | 985mm |
| Width of seat | 50cm |
| Seating capacity | 4 |
| Dry Weight(with batteries) | 480kgs |
| Carrying Capacity | 380kgs |
| Turning radius (m) | 3.5m |
| Maximum speed | 40km/h |
| Power system |
| Driving system | Gear-driven, Stepless speed change, Electric rear drive |
| Motor | 4 KW AC Motor |
| Battery | Maintenance free battery 8V × 6pcs OR 48V Lithium battery |
| Charger | 48V 25A computer controlled charger |
| Speed controller | AC controller system |
| Gear ratio | 12.49 |
| Maximum climbing ability | 30% |
| Steering and Suspension |
| Steering system | Rack and pinion steering system, automatic rocker compensating function |
| Front suspension | Macpherson independent suspension |
| Rear suspension | Multileaf spring suspension + cylinder hydraulic shock absorber |
| Brake system | Rear drum brake +Electric parking system |
| Automatic speed control system | Controller+ Induction motors |
| Autobrake System | Controller+ Induction motors |
| Braking distance | ≤ 4m |
| Wheel & Tyre |
23×10-12,4layer superior tread tire with Aluminum alloy wheel hub
|
