US$3,000.00-50,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Transmission
Hydraulic Transmission
Drive Type
Electric Drive
Certification
CE, SGS, Eac
Engine Model
Yunnei490 Turbocharging
Transport Package
Customized
Specification
Multi-specification
Trademark
tianyi OEM acceptable
Origin
Zaozhuang Shandong China
Product Description
Mini Crawler Electric Excavator Product Description
| Item NO. | | HM1500X | HM2000X | HM2500X | HM3000X | HM3500X | HM4000X |
| Engine Type | | Yunnei490 Turbocharging | Yunnei 4102 Turbocharging | Yunnei 4102 Turbocharging | Yuchai 4105 Turbocharging | Yuchai 4105 Turbocharging | Weichai 6105 Turbocharging |
| Engine power | KW | 58 | 76 | 76 | 85 | 85 | 92 |
| DrumCapacity | m3 | 2 | 3.5 | 4 | 5 | 5.5 | 6.5 |
| Valid output | m3 | 1.5 | 2 | 2.5 | 3 | 3.5 | 4 |
Overall dimension Length*Width"Height | mm | 5350*1800*2900 | 5450*2450*2800 | 5450* 2450*2800 | 6150*2700*3350 | 6150*2700*3350 | 6650* 2860*3350 |
| Axle base | mm | 2450 | 2400 | ! 2400 | 2450 | 2450 | 3200 |
| Front wheel base | mm | 1500 | 1620 | 1620 | 1680 | 1680 | 2000 |
| Rearwheel base | mm | 1500 | 1620 | 1620 | 1680 | 1680 | 2000 |
| Dumping height | mm | 1080 | 1250 | 1250 | 1400 | 1400 | 1500 |
| Minimum ground clearance | mm | 270 | 280 | 280 | 290 | 290 | 300 |
| Total weight(KGS) | KGS | 4500 | 6200 | 6200 | 8000 | 8000 | 10500 |
| Fuel consumption (Theoretical)L/H | L/H | 5.0-7.0 | 6.0-8.0 | 6.0-8.0 | 8.0-10.0 | 8.0-10.0 | 10.0-12.0 |
| Maximum drive speed | KM/H | 25 | 25 | 25 | 25 | 25 | 30 |
| Tankrotationspeed | Turn/minute | 16 | 16 | 16 | 18 | 18 | 20 |
| Tank rotation angle | ° | 0 | 180/270 | 180/270 | 180/270 | 180 | 180/270 |
| Drive Bridge | | small hub reductor | small hub reductor | small hub reductor | big hub reductor | big hub reductor | ZL-30 |
| Gear box | | 265 splitted | 265 | 265 | 280 | 280 | 315 |
| Tire Dimensions (Front) | | 23.5-16 | 20.5-16 | 20.5-16 | 12R22.5(Double Tire)16/70R20(SingleTre) | 12R22.5(Double Tire)16/70R20(Single Tire) | 18/70-20 |
| Tire Dimensions (Rear) | | 23.5-16 | 20.5-16 | 20.5-16 | 12R22.5or16/70R20 | 12R22.5or16/70R20 | 18/70-20 |
| Braking distance | mm | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 |
| Engine oil capacity | L | 12-13 | 13 | 13 | 13 | 13 | 22 |
| Hydraulic oilcapacity | L | 120 | 120 | 120 | 120 | 120 | 150 |
| Hydraulic oiltype | L | No.46 efficient wearable | No.46 eficient wearable | No.46 fficient wearable | No.46 eficient wearable | No.46 eficient wearable | No.46 efficient wearable |
| Fuel tank | L | 120 | 120 | 120 | 120 | 120 | 150 |
| Water tank | L | 500 | 750 | 750 | 750 | 750 | 750 |
| Small pump displacement | LMINUTE | 120 | 130 | 130 | 150 | 150 | 150 |
| Big pump displacement | LMINUTE | 120 (sinking pump) | 150 | 150 | 150 | 150 | 150 |
| Radius of turning circle | | 6 | 6 | 6 | 6 | 6 | 7 |
| Bucket capacity | M3 | 0.4 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
| Transmission oil type/capacity | L | No.8 transmission oil/21-23 | No. 8 transmission oil/50 | No.8 transmission oil/50 | No.8 transmission oil/50 | No.8 transmission oil/50 | No.8 transmission oil/50 |
| Axle gear oil type/capacity | L | No.18 double curve bight/ | No.18 double curve bight/3.5 | No.18 double curve bight/3.5 | No.18 double curve bight/3.5 | No. 18 double curve bight/3.5 | No. 18 double curve bight/3.5 |
| Hub reduction gear oil type/capacity | | No. 18 double curve bight/ | No.18 double curve bight/18 | No. 18 double curve bight/1.8 | No.18 double curve bight/1.8 | No. 18 double curve bight/1.8 | No. 18 double curve bight/1.8 |
| Double tire pressure | Bar | / | 10 | 10 | 10 | 10 | 10 |
| Single tire pressure | Bar | 6 | 6 | 6 | 6 | 6 | 6 |
| Tank pressure | Bar | 4.0-8.0 | 4.0-8.0 | 4.0-8.0 | 4.0-8.0 | 4.0-8.0 | 4.0-8.0 |
| Brake mode | | Disc brake | Disc brake | Disc brake | Disc brake | Disc brake | Disc brake |
Company Overview
Zaozhuang Tianyi Industry Co., Ltd., established in 2002, is located in Zaozhuang City, Shandong Province, China. Covering an area of 30,000 square meters with a building area of 23,000 square meters, our company currently employs over 200 staff members. As a high-tech enterprise, we specialize in the research, development, production, sales, and service of hydraulic fluid pipes, related fittings, base oils, and lubricant products.At present, our company has developed four product series: Series 1: Hydraulic fluid pipe series. Series 2: Fittings series. Series 3: Base oil and lubricant series. Series 4: Engineering Machinery Series.
Tianyi has successively been recognized as a national high-tech enterprise, Shandong Provincial Enterprise Technology Center, Shandong Provincial "Specialized, Refined, Unique and New" Small and Medium-sized Enterprise, Shandong Provincial Intelligent Manufacturing Pilot Enterprise, one of the first batch of technological innovation project enterprises in Shandong Province, Zaozhuang City Science and Technology Little Giant Enterprise, Zaozhuang City Hydraulic Pipeline Technology Innovation Key Laboratory, and a trustworthy enterprise for national mining safety logo quality products, among others.Zaozhuang Tianyi Industry Co., Ltd., established in 2002, is located in Zaozhuang City, Shandong Province, China. Covering an area of 30,000 square meters with a building area of 23,000 square meters, our company currently employs over 200 staff members. As a high-tech enterprise, we specialize in the research, development, production, sales, and service of hydraulic fluid pipes, related fittings, base oils, and lubricant products.At present, our company has developed four product series: Series 1: Hydraulic fluid pipe series. Series 2: Fittings series. Series 3: Base oil and lubricant series. Series 4: Engineering Machinery Series.
Tianyi has successively been recognized as a national high-tech enterprise, Shandong Provincial Enterprise Technology Center, Shandong Provincial "Specialized, Refined, Unique and New" Small and Medium-sized Enterprise, Shandong Provincial Intelligent Manufacturing Pilot Enterprise, one of the first batch of technological innovation project enterprises in Shandong Province, Zaozhuang City Science and Technology Little Giant Enterprise, Zaozhuang City Hydraulic Pipeline Technology Innovation Key Laboratory, and a trustworthy enterprise for national mining safety logo quality products, among others.
