PVC Vinyl Flooring Tiles ESD Floor for Electronic Workshop/Clean Room/Hospital

Product Description

Product Description
Anti-static Floor tile is made of PVC, plasticizer, stabilizer, coupling reagents and conductive materials, has permanent anti-static function.
Anti-static flooring tile surface uses PHPP technology. The full name of "PHPP" is "continous pressure airtight glossy surface treatment". It uses the physical method, rolling the flooring in high pressure airtight space to increase its density, sealing the surface pore and adding surface gloosiness and scratch resistance.
Anti-static floor tiles will be anti-pollution permanetly, easy to maintenance and preventing surface damage, making it more glossy and durable. Structure
Product Parameters

Item	Conductive Tile	Dissipative Tile
Thickness EN428	2.0mm 2.5mm 3.0mm	2.0mm 2.5mm 3.0mm
Size En426	600 * 600mm 900 * 900mm	610 * 610mm 900 * 900mm
Weight EN430	2.0mm:3.8kg/m² 2.5MM:4.8kg/m² 3.0mm:5.8kg/m²	2.0mm:3.8kg/m² 2.5MM:4.8kg/m² 3.0mm:5.8kg/m²
Electric properties DIN51953,ASTMF-1550 or NFPA99	2.5*10^4~10^6Ω	10^6~10^9Ω
Decay time SJ/T10694-2006(IVI<100V)	EQUAL 0.4S	EQUAL 0.4S
Charge voltage SJ/T10694-2006(IVI<100V)	EQUAL 70	EQUAL 70
Fire resistance grade DIN 4102	B1	B1
Combustion properties SJ/T11236-2001(<10s, reached FV-O grade)	EQUAL 0.35s IFV-0	EQUAL 0.35s IFV-0
Amount of anti-wear SJ/T11236-2001(≤0.020g/cm²,100r)	EQUAL 0.014	EQUAL 0.014
Anti-wear Properties EN660pt	ITEN-T<2.0mm³	ITEN-T<2.0mm³
Wheel pressure EN425	No influence	No influence
Residual concavity EN433,DIN51955	0.03mm(2.0mm) 0.035mm(2.5mm) 0.04mm(3.0mm)	0.03mm(2.0mm) 0.035mm(2.5mm) 0.04mm(3.0mm)
Demensional stability EN 434	≤0.10%	≤0.10%
Color fastness IDO105BO2	At least 6	At least 6
Resistance to chenmicals DIN423,DIN51958	Offers excellent resistance ask for special sheet	Offers excellent resistance ask for special sheet
Impact sound absorption VLI,ISO104,ISO717	Approx 2dB	Approx 2dB
Standard for health care facilties NFP A99	Confirms to the requirement of NFPA99 in effect at the tine of installation

Flooring Advantages
(1) Widely Used
KANGMAN Anti-static Floor tile permanent anti-static property. The products are widely used in the place of precise instrument and professional equipment, including electronics, clean room, computer room, hospital, telecommunication, airspace, etc.
(2) Environmentally-friendly
Comply with ISO14001, using European advanced production technology. Insure the raw materials and production meet European standard.
(3) Durable
Anti-static Vinyl Flooring has excellent stability and wear resistance, meet the usage of all kind of public huge traffic site, durable, perfect stress resistance and wear resistance.
Flooring design
Our anti-static floor tiles have regular colors.After you place your order, we usually arrange shipment to you immediately.At the same time, our anti-static floor tiles also have customizable patterns and colors, customized according to your needs.Available colors
Customizable colors
Installation Instructions
KANGMAN Anti-static floor tile should be installed on sub floors that are leveled, smooth and free of cracks. Residual humidity should be under 2.5% tested with the CM Dumb test. Tiles Floor, adhesive and installation site should reach a temperature of at least 18ºC at least 24 hours before installation. and paste the tiles with qualified conductive glue below 105 Ohm. For futher details on installation methods, please ask us.
Preparation before construction
Clean up the construction site and use professional tools to check the flatness of the ground. Repair any uneven areas. Carefully check the floor materials and prepare auxiliary materials and tools.
Construction steps: 1. Lay the copper foil network, 2. Apply adhesive 3. Floor laying 4. Welding 5. Cleaning and inspection
Materials and Tools
Maintenance:1.KANGMAN floor is unpermeable, the surface dirty is easy to clean.
2.Avoid sharp scratches on the floor by hard object, and maintain a smooth surface.
3.Cleaning the floor by neutral detergent, dry after washing, then coated with anti-static wax.
4.Serious dirty or spots can be used to clean the floor cleaning machine.
Application
Our anti-static flooring tiles suitable for many ranges of industries, including electronics manufacturing, clean rooms, laboratories, medical facilities, and areas handling flammable materials.our ESD flooring tiles solutions help protect sensitive equipment and designate electrostatic discharge-protected areas. This reduces the likelihood of harm to employees, facilities, and equipment.
Examples of facilities where ESD flooring is used:
1. Electronics manufacturing and assembly
2.Electronics testing and repair
3.Flight command centers
4.Computer server rooms and data centers
5.Clean rooms
6.Laboratories
7.Medical facilities
8.Operating theaters in hospitals and medical settings
9.Facilities where flammable liquids or gases are present
10.Any manufacturing or assembly business that uses electronics
Quality Control and Assurance
1.The produces conductive properties have been tested before out of the factory, in compliance with quality standards.
2.The sales representatives can also provides technical guidance or support in the job site.
3.Whithin 1 year from purchase, no product defects in the materials and technology. Compliance with Karmeen regulations for the installation and maintenance. KANGMAN gives 10-year guarantee (except for human reasons).
4.Above guarantee replace any other assurances, including, but not limit to, any guarrantee implied in the business feasibility or special purpose.
Company Profile
KANGMAN Group was founded in 2003, we specializing in Homogeneous floor, Heterogeneous floor, Quickfix floor, Wall Panel, LVT floor, SPC Click Flooring, ESD floor and New Decorative Materials with 2 manufacturing quarters located in Shanghai and Zhejiang Province. Prized with "Shanghai High-Tech Enterprise" and "Shanghai Famous Brand", Participated in establishing national PVC floor standard. We have 135 dealers in China. Our products has been exported to more than 50 countries and regions all over the world. Turnover at 150 million USD per year.
Certifications
FAQ
Q1: Can you manufacture products according to sample
A1: Yes, We can produce by your sample or technical drawing.We have R&D team, and also help to develop new molds.
Q2: What about the payment methods? A2: We accept T/T, L/C, DP for big or small amount, you can pay us by PayPal, Western Union, Money-gramand etc. Q3:How much does it cost to ship to my country ? A3:It depends on seasons and which country. Q4: What's your delivery time? A4: Very Quick Lead Time. 7-25 days. We keep stock for our regular products.Q5:Can i print our logo on your products? A5:Yes, of course. Q7:Can your customize my products in special shape? A7:Yes, Customized Colors and Size. Q8:How can you make sure we receive the products with high quality? A8:Our QC team will inspect each batch of products before delivery.All the raw material we use eco-friendly material and meet EU standard and US uniform, we have certificates of CE,SGS.
