High Quality Concrete Floor Shot Blasting Machine/Shot Blaster

Product Description

Product Description
water and glass dustless blasting machine
I. Technique Parameter
(1). Blast tank

Technical Paramete	DB150	DB225	DB500	DB800	DB1500	DB3000
Blasting mode	air jet	air jet	air jet	air jet	air jet	air jet
Capacity	0.03m³	0.06m³	0.14m³	0.23m³	0.42m³	0.85m³
blast time	~15min	~30min	~60 min	~90 min	~2+ hours	~4+ hours
Compressor	60+CFM	185+CFM	185+CFM	300+CFM	425+CFM	425+CFM
Size (L/B/H(mm)	1067/584/533	1397/660/863	1397/914/1016	1626/914/1016	1981/1245/1245	2490/1245/1245
Weight	72 kg	120 kg	167 kg	194 kg	380 kg	544kg
Operating Pressure	30-150 PSI	30-150 PSI	30-150 PSI	30-150 PSI	30-150 PSI	30-150 PS
Operating tube length	10m	10m	10m	10m	10m	10m
Blasting nozzle diameter	Φ10mm	Φ10mm	Φ10mm	Φ10mm	Φ10mm	Φ10mm

(2). Requirement for air compressor
4-10 bar, 185-375 CFM, 30-150 PSI, 0.2-1.0 Mpa
Air consumption: 5.2m³/min
(3). Includes
A. 10m blast hose(diameter is 32mm)
B. Deadman activator valve
C. Boron carbide nozzle(diameter is 10mm)
D. Fill funnel
E. Lifetime warranty on blast pot
(4). Consumables
II. Commercial terms
1. This is FOB price, it don't include freight and air compressor price, customer need to prepare it based on air consumption of each model.
2. Production time is 20 days after receiving the payment.
3. Payment terms: payment term is 100% in advance by TT.
4. Packaging: Plywood box
5. Warranty: one year from delivery time.
6. Delivery port: Qingdao port, China
III. Product Application
Our dustless blasting machines are mainly designed and integrated with the wide range of nozzles, wet blast attachments, internal pipe cleaning devices, dust free blasting heads, abrasive control device.

Dustless blasting recognizes the needs of the industry and our machines offer all the features that the professional use requires. All machines can be fitted with a well designed and proven single piece remote control dead man switch and silencer which significantly reduce labour cost, improve efficiency of abrasive, performance and safety.

The machines are constructed for a maximum 150 PSI working pressure. The pneumatic abrasive remote control valve can achieve operators to stop or start .
IV. Main Features
1. High quality surface appearance
2.High productivity efficiency
3.Low cost
4. Environmental friendly
5. Lower abrasive consumption
6.Safe, no sparking
7.Less contamination
8.Not necessary to stop nearby jobs.
9.Removes scale for a paint ready surface.
10. Requires only a parking space
11. Does not warp metal
12. Leaves a primer-ready surface
13. Easy to clean up
14. Prevents rust for 72 hours
V. Details picture
