High Gain Dual Handheld 8 Port Directional Panel Antenna Customized Frequency

Product Description

Electrical Specifications
FrequencyRange	350-400/400-450/450-500/500-560 700-775/775-850/850-930/930-1020
Gain(dBi)	4-6±1dBi
VSWR	≤2.0
Polarization	8*/Vertical/Horizontal
Horizontal Beamwidth(0º)	75±10°/45±5°/ 32±3°
Vertical Beamwidth(0º)	65±10°/35±5°/16±3°
Front-to-back ratio(dB)	≥15/≥18/≥20/≥23
Input Impedance(Ω)	50Ω
Maximum input power(W)	50W
Inpur connector type	8*N-J with 1.5M Black RG195 Cable
Lightning Protection	DC Ground
Mechanical Specifications
Dimensions­mm(Height/Width/Depth)	820*390*50mm
Packing size(mm)	830*410*180mm
Antenna weight(kg)	4.5±0.3Kg
Operational Humidity(%)	10-95
Radome Color	Black/Navy
Radome material	ABS
Operating temperature(ºC)	-30~65°
Installution Method	Handheld

Shenzhen RDSignal Technology Co., Limited is one of the leading suppliers which specializes in designing and manufacturing RF Jamming Equipment and Wireless Coverage Products.
RF Jamming Equipment include Cell Phone Signal Jammer and RF Communication Jammer(20-6000MHz).
RDSignal Technology Co.,Ltd. is the foremost innovator in the field of RF jamming, offering a comprehensive range of jamming equipment and systems which have a proven record of reliability and performance in all types of applications and environmental conditions.
Such as, Drone jammer, UAV jammer, High power bomb jamming devices, IED jammers, Digital programable jammer, VIP Convoy Bomb Jammers (RCIED Jammers), Mobile Phone Signal Jammers, Prison Jammers, Portable Jammers, Handheld Jammers, to suit all types counter terrorism activities.
RDSignal products have been exported to more than 60 countries and regions around the world. Such as Southeast Asia, Africa, Europe, South America and the Middle East.
Let us hand in hand and create a glorious cause!
Exhibitions
FAQ
Q1. Could I get a sample before bulk order?
Yes, we offer the sample for all models but charged.
Q2. What should I do if I don't know about frequency in my country?
Please feel free to contact us with your inquiry, we will find the frequency you need and address your problems.
Q3. Do you accept OEM/ODM order?
Yes, we can customize the brand logo, colors, and frequencies.
Q4.Shipment Date

Sample	3-5 business days
<20 pcs="">	7-15 days
20-50 pcs	15-24 days
>50 pcs	Negotiate

<20 pcs="">Q5: Delivery Date of the sample by DHL/FedEx

USA/Canada/Europe/Asia	3-5 days
Middle East/Latin American	5-7 days
African	3-7 days

Q6.Payment Method
T/T, Western Union, Paypal, and Credit Card are available,
but we suggest paying by Made In China, the most favor, and security method.
*Other methods please contact us with more details.

---
