ISO PLC Control Automatic Belt Conveyor Roller Shaft Double End Holes Drilling Lathe Making Machine Conveyor Idler Turning Manufacturing Machine for Mining

Product Description

1, Machine features:
This machine tool is a special machine tool designed to process the ends of steel pipe of belt conveyor. It is suitable for all kinds of rollers produced at home and abroad (cast iron or punching bearing seat).The machine adopts mechanical fast clamping device, reliable clamping, simple and convenient adjustment of clamping force, hydraulic drive of cutter feed, adjustable speed without electrode, and hydraulic synchronous loop of right and left two feed cylinders, which can feed at the same time and return the cutter at the same time.
The radial feed adopts manual operation, which can be adjusted precisely according to the machining requirements. It is equipped with a hydraulic automatic tool mechanism, which can automatically let the cutter when it is fed to a predetermined position. Avoid scratching the machined surface. The control system based on the imported programmable controller (PLC) is used for electrical control.
The equipment has the advantages of wide application, high reliability and high working efficiency. It is especially suitable for the processing and production of batch rollers.
2, Technical specification:

project	parameter
model	TC-160*2200
Machine tool spindle center height	900mm
Outer diameter of processed steel pipe	Ф76-159mm
Machined steel pipe length	200-2200mm
Depth of both ends of processing	0-70mm
Sliding speed of sliding seat	2m/min
main shaft speed	500r/min
feed rate	Hydraulic stepless speed regulation
cutting depth	0-3mm
Tool holder radial feed scale value per lattice	0.05mm
Accuracy of Radial tool Repeating-positioning of tool holder	0.05mm
Main drive motor	4kw 1450r/min
Workpiece clamp motor	1.5kw 1450r/min
Working pressure of hydraulic system	2.5-4Mpa
rate of flow	0-25L/min
contour size of the unit(s)	4500×1000×1200mm
weight	2500Kg

Introduction of Cangzhou Terok International Trade Co., Ltd
Cangzhou Terok International Trade Co., Ltd. is a comprehensive enterprise integrating international trade, production, and sales. We are committed to providing high-quality products and services to global customers, and we also specialize in the production and sales of roller bearing housings, steel pipes, roller bearings, seals, and roller machine tools. The company boasts an experienced team adept at handling various international trade matters, including but not limited to import and export business, market development, and supply chain management. Additionally, our production team possesses profound professional knowledge and technical expertise in the fields of roller accessories and roller machine tools, enabling us to provide customers with high-quality products and customized solutions.
With our profound understanding of the market and strong resource integration capabilities, Cangzhou Terok International Trade Co., Ltd. has earned a solid reputation in the industry. We continuously strive for excellence and are committed to growing together with our partners to achieve mutual success. Whether it's international trade or the production and sales of roller accessories and roller equipment, we will repay every customer's trust and support with our professional attitude and high-quality products.
The company boasts a professional R&D team that continuously explores and introduces production equipment for rollers that reduce operational energy consumption and maintenance costs, such as semi-automatic machine tools for rollers, semi-automatic lines for roller processing, and fully automatic lines for roller processing. Simultaneously, the company creates greater value for its customers. The company primarily produces and sells rollers, stamped bearing housings for rollers (diameter φ60-φ219) in TD75 and DTII types, stamped center pillars, side pillars, H-frame tube housings, support plates, foot plates, waist drum rollers, seals, and various other mining conveyor components and stamped products.
In terms of sales and service, Cangzhou Terok is customer-oriented, providing personalized solutions and establishing a comprehensive pre-sale, in-sale, and after-sale service network to ensure that customers can enjoy timely and efficient support from anywhere in the world.
Cangzhou Terok International Trade Co., Ltd. has always adhered to the philosophy of "quality first, integrity in business". We have been dedicated to the field of international trade, working hand in hand with global partners to contribute to the development of the industry, and steadily striving towards becoming a top-tier international supplier.

---
