Mindvision USB3.0 Industrial Camera 2MP 165.5fps 2/3′cmos Global Shutter Machine Vision C Mount Area Scan Camera

Product Description

Model	MV-SUA202GC			MV-SUA202GM
Camera Type	Color			Mono
Resolution @ Frame Rate	1920*1200@165.5fps
Pixel size	4.8umx4.8um
Pixel Bit Depth	10 bit
Sensitivity	7.5 V/lux-s @550nm
Acquisition Mode	Continuous / Soft Trigger / Hard Trigger
Maximum Gain (multiple)	8
Exposure Time Range(ms)	0.0039~356.1ms
Frame Buffer	128M Bytes
User-defined Data Area	2K Bytes
Video Output Format	Bayer 8bit			Mono 8bit
GPIO	1 opto-coupler isolated input, 1 opto-coupler isolated output, 1 non-isolated input and output
Lens Interface	C-Mount( CS Mount for option)
Power supply	5V, by USB bus power
Power	<3W
External Dimension	29X29X32.7(mm)(Lens base and rear shell interface are not included)
Weight	75g
Operating System	WINXP, WIN7/8/10 32 & 64-bit systems, Linux and ARM Linux drivers and Android platform drivers MAC OS system
Drive program	DirectShow components Halcon special components Labview dedicated drive OCX components TWAIN components
Programming language	C/C++/C#/VB6/VB.NET/Delphi/BCB/Python/Java
Certification	Rhos,CE

Global Shutter Optional

Product Model

Pixel

Resolution

Frame Rate(Fps)

Sensor Size

Pixel Size

Min Exposure

MV-SUA33GC/M

0.3MP

640*480

791

1/5.6''

4.0um

0.0025ms

MV-SUA34GC/M

0.3MP

640*480

454

1/4''

4.8um

0.0045ms

MV-SUA40GC/M

0.4MP

720*540

523.75

1/2.9''

6.9um

0.0032ms

MV-SUA133GC/M

1.3MP

1280*1024

241.5

1/2.7''

4.0um

0.004ms

MV-SUA134GC/M

1.3MP

1280*1024

216.25

1/2''

4.8um

0.0045ms

MV-SUA200GC/M

2MP

1600*1200

60

1/1.8''

4.5um

0.0157ms

MV-SUA202GC/M

2MP

1920*1200

165.5

2/3''

4.8um

0.0039ms

MV-SUA230GC/M

2.3MP

1920*1200

165.25

1/1.2''

5.86um

0.0049ms

MV-SUA231GC/M

2.3MP

1920*1200

40

1/1.2''

5.86um

0.0201ms

MV-SUA300GC/M

3MP

2048*1536

55.75

1/1.8''

3.45um

0.0114ms

MV-SUA501GC/M

5MP

2448*2048

40.5

2/3''

3.45um

0.0118ms

MV-SUA505GC/M

5MP

2592*2048

42.75

2/3''

3.2um

0.0113ms

MV-SUF401GC/M

4MP

2048*2048

88

1''

5.5um

0.0054ms

MV-SUF890GC/M

8.9MP

4096*2160

32

1''

3.45um

0.0141ms

MV-SUF1200GC/M

12MP

4096*3000

23.5

1.1''

3.45um

0.0141ms

MV-SUF1205GC/M

12MP

4096*3072

28.5

1''

3.2um

0.0113ms

MV-SUC1206GC/M

12MP

4112*3088

30

1.1''

3.5um

0.0533ms

MV-SUS240GC/M

2.4MP

2048*1200

158.3

1/1.7''

4um

0.0084ms

MV-SUS507GC/M

5MP

2448*2048

60

2/3''

3.4um

0.003ms

Rolling Shutter Optional

Product Model

Pixel

Resolution

Frame Rate(Fps)

Sensor Size

Pixel Size

Min Exposure

MV-SUA502C/M

5MP

2592*1944

59

1/2.5''

2.2um

0.0084ms

MV-SUA630C/M

6.3MP

3088*2064

59.5

1/1.8''

2.4um

0.008ms

MV-SUA800C/M

8MP

3840*2160

45.75

1/1.8''

2.0um

0.02ms

MV-SUA1000C/M

10MP

3664*2748

8

1/2.3''

1.67um

0.0545ms

MV-SUA1201C/M

12MP

4000*3000

32

1/1.7''

1.85um

0.0102ms

MV-SUA1600C/M

16MP

4608*3456

12

1/2.3''

1.34um

0.0233ms

MV-SUA2000C/M

20MP

5488*3672

19.5

1''

2.4um

0.0138ms

MV-SUA2002C/M

20MP

5488*3672

19

1''

2.4um

0.0143ms

MV-SUF1200C/M

12MP

4080*3072

30.75

1''

3.1um

0.0201ms

MV-SUC240M

2.4MP

1936*1280

30

1.5''

9.9um

0.0107ms

MV-SUC404C/M

4MP

2048*2048

85

1.1''

5.94um

0.0327ms

MV-SUS502M

5MP

2592*1944

59

1/2.5''

2.2um

0.0084ms

If you have more requirement, click to contact us Recommended by seller Support Customization Bands ODM
Ultraviolet, visible light, near infrared, short wave infrared, far infrared
Interfaces ODM
USB2.0/USB3.0/ Gigabit/10 Gigabit/CXP/Wireless
Additional functions ODM
10/Autofocus/waterproof housing/Special construction pieceEquipped/battery powered
Sensor
Sony/Onsemi/Gpixel/Smartsensor/OV/Etc Interface Type Wide Range of Applications It is suitable for electronic semiconductor, factory automation, food andbeverage, medical packaging, image measurement and other industries. Industrial Inspection Intelligent Traffic Systems Education Industry Express Delivery Biological Research Medical Industry About MindVision Shenzhen MindVision Technology Co., Ltd. MindVision is a professional industrial camera manufacturer. We have been focusing on the R&D, production and manufacturing of industrial cameras, and we are the first company in China to realize the mass production of Gigabit network industrial cameras.We founded in Shenzhen, have product centers and R&D bases in Changsha, Hunan Province and Wuxi, Jiangsu Province, with a total of nearly 300 employees. MindVision product line is complete, including area scan cameras, line scan cameras, thermal imaging cameras, smart cameras, 3D cameras, etc., and also provides customized services. Why choose MindVision? Own Factory Complete Product Line Large Scale Self-developed Software Professional Marketing After-sales Service Exhibition Exhibitions in Germany At the Munich Exhibition in Germany, MindVision gained the attention of many foreian customers with advanced
