| Model | Specification |
| JT-T56 | Maximum spindle rotation diameter | mm | ∅550 |
| Maximum machining diameter | mm | ∅400(80-8 stations-380 tool disc) |
| Maximum machining length | mm | 500 (200 Spindle) |
| Workpiece clamping method | | Hydraulic chuck (A2-6, 8-inch) |
| Spindle speed range | r/min | 0-4500 |
| Spindle nose specification | | A2-6 |
| Spindle through-hole diameter | mm | ∅66(200 Spindle) |
| X-axis rapid traverse speed | mm/min | ≤24 |
| Z-axis rapid traverse speed | mm/min | ≤24 |
| Ball screw specification | | X-3210-C5-THK (Coupling end ∅22) |
| | Z-3210-C5-THK (Coupling end ∅22) |
| Linear guide specification | | X-35-H grade-PMI (Extended slider) |
| | Z-35-H grade-PMI (Extended slider) |
| Ball screw bearing | | X-axis motor end - 2562 / Support end - 2562 |
| | Z-axis motor end - 2562 / Support end - 2562 |
| X-axis travel distance | mm | 460 |
| Z-axis travel distance | mm | 620 |
| X/Z axis repeatability accuracy | mm | 0.003 |
| Height from the bottom of the foot to the spindle center | mm | 1044 |
| Machine weight | kg | About 3500 |
| Optional Configurations | 170-A2-6 spindle (purchased) | | Hydraulic - V-belt / Timing belt |
| | Front 4-7017 / Rear 4-7015 |
| 200-A2-6 spindle (purchased) | | Hydraulic - V-belt / Timing belt |
| | Front NN3020 + 100BTR / Rear NN3018 |
| 2500-A2-8 spindle (purchased) | | Hydraulic - V-belt / Timing belt |
| | Front NN3026 + 130BTR / Rear NN3022 |
| 80 Servo turret | | 8 stations - 330 tool disc / 12 stations - 330 tool disc |
| 80 Japanese-style servo turret | | 8 stations - 330 tool disc / 12 stations - 360 tool disc |
| Turret external turning tool | | 25 |
| Turret boring tool diameter | mm | φ32/φ40 |
| Tailstock maximum travel | mm | 300 |
| Tailstock taper hole | | M#5 |
| Tailstock operating mode | | Hydraulic cylinder - φ50 |
| | Ball screw - 3210 |
| | Linear guide - 35 (extended slider) |
| Tailstock ball screw bearing | | 51109/61909 |
| Servo main motor board | | 5.5/7.5/11/15 |
| Chip conveyor | | Side discharge / Rear discharge |
