CNC Vertical Machining Center with Standard 16tools (VMC850)

Product Description

CNC Machining Center with Standard 16tools (VMC850)
Vertical machining center refers to a machining center with the axis of the main shaft and the worktable set perpendicular to it. It is mainly suitable for processing complex parts such as plates, discs, molds and small shells. The vertical machining center can complete the processes of milling, boring, drilling, tapping and thread cutting.

Specification	Unit	VMC850	VMC850L
Table size	mm	1050x500	1050x500
Travel X-axis	mm	800	800
Travel Y-axis	mm	500	500
Travel Z-axis	mm	600	600
Spindle center to column guide way face	mm	560	560
Spindle nose to work table	mm	110-710	110-710
T-slot No./width/distance		5/18/90	5/18/100
Spindle taper		BT40	BT40
Max. diameter of tools	mm	Φ80/Φ130	Φ80/Φ130
Max. length of tools	kg	300	300
Rapid feeding for X	mm/min	15000	20000
Rapid feeding for Y	mm/min	15000	20000
Rapid feeding for Z	mm/min	12000	18000
Spindle max.speed	rpm	8000	8000
Main motor power	kw	7.5/11	7.5/11
Max. loading of table	kg	600	600
Net weight	kg	5500	5500
Overall dimension	cm	270x206x203	260x205x203

Standard Accessories: * FANUC 0i mate MD CNC system; * Sliding guideway for VMC850,; Linear guideway for VMC850L; * 8000rpm high speed BT40 spindle from Taiwan; * Umbrella type ATC with 16 tools capacity from Taiwan; * Separated electronic handwheel; * Interval auto-lubricating; * Full splash guard; * Ball screw from Taiwan; Optional Accessories: The 4th axis; FANUC 0i MD, SIEMENS, or other CNC system; Disc type ATC with 24 tools capacity; Auto. chip conveyor;
Our Advantages
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period.
2. Quick action and reply for the technical questions at any time in the whole life of the machine.
3. Overseas after service center available in some region.
4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Packaging & Shipping
Company Profile
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
Customer visited
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
The following is one of the most satisfactory products recommended by customers, as well as our main product categories. you can click and view

Conventional Lathe	CNC Lathe	CNC Machining Center	CNC Milling Machine
Grinding Machine	Milling Machine	Special Use Lathe	Boring Machine

FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.

---
