Large High Precision China Rectificadora CNC Universal Cylindrical Grinder Grinding Machine for Metal Processing (amoladora)

Product Description

One-stop Shopping
Please click on the picture to view the product category you are interested in

Conventional Lathe	CNC Lathe	CNC Machining Center	CNC Milling Machine
Grinding Machine	Milling Machine	Special Use Lathe	Boring Machine

Product Description
CNC cylindrical grinding machine

SPECIFICATION	UNIT	GK200-1	GK320-1	GDK200-1(GDK200-M)	GDK320-1(GDK320-M)
Distance between centers	mm	500/750	1000/1500	500/750	1000/1500
Center height	mm	135	180	135	180
Dia. ground(O. D)	mm	8-200	8-320	8-200	8-320
Max. weight of workpiece	kg	50	100	50	100
Workhead spindle taper	/	MT4	MT5	MT4	MT5
Workhead spindle speed(stepless)	r/min	60-600	35-350	60-600	35-350
Max. dimension of wheel(O. DxWxI. D)	mm	400x50x203	500x80x203	500x80x203	500x80x203
Wheel peripheral velocity	m/s	35	45	45	45
Min. set unit	mm	0.0001	0.0001	0.0001	0.0001
Max. swiveling angle of table(Clockwise)	°	5° (500), 3° (750)	3°	5° (500), 3° (750)	3°
Max. swiveling angle of table(Anticlockwise)	°	9° (500), 6° (750)	7° (1000), 6° (1500)	9° (500), 6° (750)	7° (1000), 6° (1500)
Tailstock quill taper	/	MT4	MT4	MT4	MT4
Tailstock quill travel	mm	30	30	30	30
CNC system	/	SIMENS828D,FANUC0i-TF
Wheelhead motor power	kw	5.5	7.5	7.5	7.5
Workhead motor power	kw	1.1	1.5	1.1	1.5
Roundness	um	0.5	0.5	0.5	0.5
Cylindricity	um	2(500), 3(750)	3	2(500), 3(750)	3
Roughness	um	Ra0.04	Ra0.04	Ra0.04	Ra0.04
Gross weight	tons	5.5/6	6.7/7.7	5.5/6	6.7/7.7
Packing size(LxWxH)	cm	340/400x240x220	460/560x250x220	340/400x240x220	460/560x250x220

Detailed Photos

The table (Z-axis) guide adopts open unloading hydrostatic guide structure, and the transverse feed (X-axis) adopts Swiss N/O linear guide structure. It adopts high precision roller screw drive, zero clearance, low speed and no creep.

The spindle of the grinding whel adopts large taper, four oil wedge, automatic adjustable hydro-dynamic pressure bearing, the workhead adopts hydro-static spindle center-fixed grinding structure, the tailstock adopts dense bead sleeve or linear bearing structure, the whole machine has strong rigidity and high precision

The machine bed adopts double-layer structure (finite element analysis), the casting with special ratio is cast in one piece, and the combined surface is manually precision scraped, thus the thermal deformation is stable and the accuracy is stable for a long time. Among them, GDK-M series adopts mineral bed structure, no deformation, and the accuracy is more durable and stable.

Our Advantages
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period.
2. Quick action and reply for the technical questions at any time in the whole life of the machine.
3. Overseas after service center available in some region.
4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Packaging & Shipping
Company Profile
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
Customer visited
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
The following is one of the most satisfactory products recommended by customers, as well as our main product categories. you can click and view

FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.

---
