AC Variable Frequency Drives, Kw Rated - AC10 Series #10g-43-0120-Bn

Product Description

Original and new parker AC Variable Frequency Drives, kW Rated - AC10 Series | #10G-43-0120-BN
AH500075U002
AH470330U002
AH500076U001
AH387775U001
AH385851U003
AH385851U002
10G-42-0065-BN
10G-43-0090-BN
10G-44-0170-BN
10G-44-0230-BN
10G-43-0120-BN Item Information
The AC10 variable speed compact drive is a simple, reliable and economical solution to every-day motor control applications requiring speed or torque control within the power range of 0.2kW to 180kW. Having compact dimensions and features normally only associated with higher specification AC drives, including, sensorless vector mode, output frequency up to 590 Hz, 3 phase 400VAC supplies in all 5 frame sizes and a full 150 % overload at 0.5 Hz for 1 minute, the AC10 provides an optimised solution for OEM machine builders who are looking for a compact, cost-effective, energy saving variable speed ac drive without compromising on performance.
Markets:
• Air conditioning
• Heating
• Refrigeration
• Ventilation
• Other HVAC
• Air & Gas Compressors
• Factory Automation
• Printing & Marking Equipment
• Miscellaneous Industrial
• Food & Beverage
Features/Benefits:
- Simplicity : AC10 drives are designed to reduce the time and effort required to install, setup and commission through its easy to use integrated keypad. Minimal wiring requirements and two easily accessed terminal rails make AC10 fast and simple to install, having you up and running in no time at all. Auto-tuning sensorless vector mode takes AC10 beyond simple V/Hz control, allowing users requiring greater dynamic speed or torque control for their application to benefit from the drives enhanced 0.5% speed and 5% torque accuracy.
- Reliability : Proven technology and manufacturing techniques ensure AC10 drives have been engineered and built to deliver consistently outstanding levels of performance day in, day out, ensuring maximum uptime and productivity. Thanks to its conformally coated PCBs, AC10 drives are able to withstand even the most arduous class 3C3 environment which many other AC drives in this class would struggle with, allowing you to operate the AC10 with the utmost confidence in more applications.
- Control At Your Fingertips : AC10 drives come complete with an ergonomic operator keypad as standard, featuring 4 LED drive status indicators, a 4 digit 7 segment LED display and a tactile membrane style keypad. In addition to displaying status and running information, the LED display is also used to access drive configuration parameters which can be quickly and easily changed via the keypad. The keypad can also be used to take local control of the motor to start, stop, increase or decrease motor speed. An optional keypad is also available and can be mounted remotely from the drive.
- IP20 (0.2 - 180kW) or IP66 (0.4 - 90kW) : The IP66 enclosure enables use in both indoor and outdoor applications where environmental conditions may be a concern, such as wash-down areas in food and beverage facilities and use in waste plants or rooftop units.
Applications:
AC10 variable speed drives provide a no-fuss approach to general purpose industrial motor control applications across a wide range of industries, giving users the benefits of the inherent energy-saving properties of using a variable speed drive, as well as the improved reliability and extended service life benefits associated with smoother starting and stopping of regularly cycling loads. Typical applications for AC10 drives would include :
• Conveyor
• Centrifuge
• Fans
• Mixers
• Packaging Machines
• Textile Machines
• Strapping Machines
• Labelling Machines
• Industrial Washing Machines
• Machine Tool Spindles
• Roller Doors
AC690+ Series (400/460V) Integrator Series Drive
AC690+ Series (400/500V) Integrator Series Drive
690PC /0075/400/0011/UK/0/0/0/0/B0/0/0 (690-432160CO-B00P00-A400)
690PD/0180/400/0010/UK/0/0/0/0/B0/0/0
690PC/0075/400/0010/UK/HTTL/0/SHTTL/B0/0/0
690PC /0110/400//0011/UK/0/0/0/0/BO/0/0
HTTL ENCODER TECH BOX 6054 FOR EUROTHERM
PROFIBUS TECH CARD 6055/PROF/00 EXHAUST
Original and new parker AC690+ Series Integrator Series Drive 690+0200/400/CBN/UK 132KW
Integrator 590 Series Digital DC Drive From 15 to 2700 ampere (1 to 2000 HP)
Description
The Integrator series is a single family of both AC drives (690+) and DC drives (590+) that provides the benefits of common programming, set-up and communication across both technologies. The 590+ Integrator series highly advanced DC drive meets the demands of the most complex motor control applications.
Extensive application software (including winder control as standard) together with Function Block Programming and configurable I/O creates a total drive system in a single module.

Product parameter of original parker DC drive :
590c/0350 35A 500V r eversible 591c/0350 35A 500V irr eversible
590c/0700 70A 500V r eversible 591c/0700 70A 500V irr eversible
590c/1100 110A 500V r eversible 591c/1100 110A 500V irr eversible
590c/1500 150A 500V r eversible 591c/1500 150A 500V irr eversible
590c/1800 180A 500V r eversible 591c/1800 180A 500V irr eversible
590c/2700 270A 500V r eversible 591c/2700 270A 500V irr eversible

Parameter	Current	Mode of operation	Input voltage	Dimension
591P/15A	15A	Irreversible	500-220V	375*200*220mm
591P/35A	35A	Irreversible	500-220V	375*200*220mm
591P/40A	40A	Irreversible	500-220V	434*200*292mm
591P/70A	70A	Irreversible	500-220V	434*200*292mm
591P/110A	110A	Irreversible	500-220V	434*200*292mm
591P/165A	165A	Irreversible	500-220V	434*200*292mm
591P/180A	180A	Irreversible	500-220V	485*250*180mm
591P/270A	270A	Irreversible	500-220V	485*250*180mm
591P/380A	380A	Irreversible	500-220V	700*253*358mm
591P/500A	500A	Irreversible	500-220V	700*253*358mm

Eurotherm (Parker) DC Drives

Integrator 591 Series Digital DC Drive From 15 to 2700 ampere (1 to 2000 HP)
Description
The Integrator series is a single family of both AC drives (690+) and DC drives (590+) that provides the benefits of common programming, set-up and communication across both technologies. The 590+ Integrator series highly advanced DC drive meets the demands of the most complex motor control applications.
Extensive application software (including winder control as standard) together with Function Block Programming and configurable I/O creates a total drive system in a single module..
Innovation
The 590Plus series introduced a new world, radical approach, in DC drive design: the philosophy of DRV.
Each 590Plus DRV is internally integrated with all auxiliary power components.

TECHNICAL SPECIFICATIONS Input Power 50-60Hz ±5% Three Phase 110-220Vac ±10% Three Phase 220-500Vac ±10% Three Phase 500-690Vac ±10% Ambient Temperature 0-45°C (Frame 15-165A) 0-35°C (Frame 180-800A) 0-40°C (Frame 900-2700A) Overload for 15 to 450A Frame 150% for 60 sec. 115% for 10 sec. Overload fro 720A and Higher Refer to manual for options

TECHNICAL CHARACTERISTICS 590Plus 4 quadrant regenerative Dual (2) Three Phase SCR bridgesi 591Plus non-regenerative 2 quadrant Single (1) SCR bridge Variable Field control with SCR's Available frames by armature current rating 15, 35, 40, 70, 110, 165, 180, 270, 380, 500, 725, 830, 1200, 1580, 1700, 2200 and 2700 Ampere. (DRV Version available only 15 to 165A frame)

INPUTS/OUTPUTS Analog Inputs (5 total, 4 configurable) 12 bit; 0-±10V Analogue Outputs (3 total, configurable) 10 bit; 0-±10V Digital Inputs (9 total, 5 configurable) 24Vdc (max 30Vdc) Digital Outputs (3 total, configurable) 100mA max 30VdcShort circuit protected

INTERNATIONAL CODES The 590Plus complies to standard code when installed in accordance to manufacturers installation manual: EN50178 (Protection, Low Voltage Directive) EN50081-2 (1992) (EMC emissions in industrial ambience ) EN50082-2 (1995) (Immune in industrial EMC environment) EN61000-3-2 (Standard harmonics with line inductors)

Package Contents
1. The drives will be shipped via sea transportation, air transportation or express. Parcel Post is depended on the weight and destination. We get very good rates on freight shipments. Please use the shipping calculator to determine shipping costs. Shipping to a commercial location with loading dock or forklift is always the cheapest option for freight
2. Rush Delivery is available upon request. Please e-mail for quote (please include zip code) Handling Time is normally
3. business days. Please use the shipping calculator to determine transit times. (Holidays are an exception). Your tracking number will be emailed to you once your order has been shipped

220V-500V (+/- 10%)
591+ 2 Quadrant Non-Regenerative
Product Code	Frame Size	Armature Output Current (A)
591P-53215010-P00-U4V0	1	15
591P-53235010-P00-U4V0	1	35
591P-53240020-P00-U4V0	2	40
591P-53270020-P00-U4V0	2	70
591P-53311020-P00-U4V0	2	110
591P-53316520-P00-U4V0	2	165
591P-53318032-P00-U4V0	3	180
591P-53327032-P00-U4V0	3	270
591P-53338042-P00-U4V0	4	380
591P-53350042-P00-U4V0	4	500
591P-53372542-P00-U4V0	4	725
591P-53383042-P00-U4V0	4	830
591P-53412560-P00-U4V0	4	1250
220V-500V (+/- 10%)
590+ 4 Quadrant Regenerative
Product Code	Frame Size	Armature Output Current (A)
590P-53215010-P00-U4V0	1	15
590P-53235010-P00-U4V0	1	35
590P-53240020-P00-U4V0	2	40
590P-53270020-P00-U4V0	2	70
590P-53311020-P00-U4V0	2	110
590P-53316520-P00-U4V0	2	165
590P-53318032-P00-U4V0	3	180
590P-53327032-P00-U4V0	3	270
590P-53338042-P00-U4V0	4	380
590P-53350042-P00-U4V0	4	500
590P-53372542-P00-U4V0	4	725
590P-53383042-P00-U4V0	4	830
590P-53412560-P00-U4V0	4	1250
Product Code	DESCRIPTION
506-00-20-00	3A Non-Isolated 110/240V AC Supply
507-00-20-00	6A Non-Isolated 110/240V AC Supply
508-00-20-00	12A Non-Isolated 110/240V AC Supply
512C-04-00-00-00	4A Two Quadrant isolated Controller
512C-08-00-00-00	8A Two Quadrant isolated Controller
512C-16-00-00-00	16A Two Quadrant isolated Controller
512C-32-00-00-00	32A Two Quadrant isolated Controller
514C-04-00-00-00	4A Four Quadrant isolated Controller
514C-08-00-00-00	8A Four Quadrant isolated Controller
514C-16-00-00-00	16A Four Quadrant isolated Controller
514C-32-00-00-00	32A Four Quadrant isolated Controller
Accessories :
Product Code	DESCRIPTION
AH387775U001	ENCODER BOARD
AH500935U001	Analog Tacho Board
598P-53260010-TP00-U4A0	EXTERNAL STACK
590DC-00-000	590C Door assembly
590PXD-0011+A89	590P Door assembly

Spare parts Available (ex-stock)


DC speed controller price/parker SDD/parker 591p DC drive Integrator 590 Series Digital DC Drive From 15 to 2700 ampere (1 to 2000 HP)
Description
The Integrator series is a single family of both AC drives (690+) and DC drives (590+) that provides the benefits of common programming, set-up and communication across both technologies. The 590+ Integrator series highly advanced DC drive meets the demands of the most complex motor control applications.
Extensive application software (including winder control as standard) together with Function Block Programming and configurable I/O creates a total drive system in a single module.

Product parameter of original parker DC drive :
590c/0350 35A 500V r eversible 591c/0350 35A 500V irr eversible
590c/0700 70A 500V r eversible 591c/0700 70A 500V irr eversible
590c/1100 110A 500V r eversible 591c/1100 110A 500V irr eversible
590c/1500 150A 500V r eversible 591c/1500 150A 500V irr eversible
590c/1800 180A 500V r eversible 591c/1800 180A 500V irr eversible
590c/2700 270A 500V r eversible 591c/2700 270A 500V irr eversible

Parameter	Current	Mode of operation	Input voltage	Dimension
591P/15A	15A	Irreversible	500-220V	375*200*220mm
591P/35A	35A	Irreversible	500-220V	375*200*220mm
591P/40A	40A	Irreversible	500-220V	434*200*292mm
591P/70A	70A	Irreversible	500-220V	434*200*292mm
591P/110A	110A	Irreversible	500-220V	434*200*292mm
591P/165A	165A	Irreversible	500-220V	434*200*292mm
591P/180A	180A	Irreversible	500-220V	485*250*180mm
591P/270A	270A	Irreversible	500-220V	485*250*180mm
591P/380A	380A	Irreversible	500-220V	700*253*358mm
591P/500A	500A	Irreversible	500-220V	700*253*358mm

We mainly supply servo motor , servo driver , servo amplifer , PLC , Encoder , Inverter , Power Supply Board ,HMI Touch Screen ......Industrial control product.Some item are NEW IN BOX , Others are secondhand product . But All the goods will be tested before shipping . Welcome to order ! Except V1000 Sereis ,we also have other series Yaskawa inverter for sell.
L1000A Yaskawa Inverters :
3.7kw: CIMR-LB4A0009FAB
5.5kw: CIMR-LB4A0015FAB
7.5kw: CIMR-LB4A0018FAB
11kw: CIMR-LB4A0024FAB
15kw: CIMR-LB4A0031FAB
18.5kw: CIMR-LB4A0039FAB
22kw: CIMR-LB4A0045FAB
30kw: CIMR-LB4A0060FAB
37kw: CIMR-LB4A0075FAB
45kw: CIMR-LB4A0091FAB
55kw: CIMR-LB4A0112FAB
75kw: CIMR-LB4A0150FAB

---
