Product Details
Product Description
Product Description
We can supply China local PMMA for you .We can supply all kinds of PMMA raw materials for you.
Product Description:
Virgin PMMA resin , Pure PMMA resin , Transparent PMMA resin , Compound PMMA resin , Modified PMMA resin , Fire resistant PMMA resin , Flame resistant PMMA resin , PMMA resin GF , Heat resistant PMMA resin , High temperature resistance PMMA resin , Low temperature resistance PMMA resin , Impact resistant PMMA resin , High quality PMMA resin , Low price PMMA resin , Outstanding PMMA resin , Excellent PMMA resin , High performance PMMA resin , High strength PMMA resin , Low flow PMMA resin , High flow PMMA resin , High RV PMMA resin , Low RV PMMA resin , Injection PMMA resin , Extrusion PMMA resin
| GENERAL INFORMATION |
| BRAND: WANHUA | GRADE: HD08L |
| MATERIAL: | PMMA |
| FEATURES: | 1. EXCELLENT TRANSPARENCY | 2. OUTSTANDING OUTDOOR DURABILITY | 3. GOOD SCRATCH RESISTANCE |
| APPLICATIONS: | GENERAL PURPOSE |
| APPEARANCE: | CLEAR/TRANSPARENT |
| FORM: | PELLETS |
PROCESSING
METHOD: | 1. EXTRUSION |
Applications:
Technical Data Sheet:
| Properties | Test Method | Unit | Value |
| Physical |
|
|
|
| Density | ISO 1183 | g/cm3 | 1.19 |
| Shrinkage | ISO 294 | % | 0.2 ~ 0.6 |
| Melt Flow Rate, 230ºC/3.8KG | ISO 1133 | g/10min | 1.5 |
| Water Absorption, 24h | ISO 62 | % | 0.3 |
| Mechanical |
|
|
|
| Tensile Strength, 5mm/min | ISO 527 | Mpa | 75 |
| Tensile Modulus , 1mm/min | ISO 527 | Mpa | 3,300 |
| Elongation, 5mm/min | ISO 527 | % | 6 |
| Flexural Strength , 2mm/min | ISO 178 | Mpa | 130 |
| Flexural Modulus, 2mm/min | ISO 178 | Mpa | 3,400 |
| Charpy Impact Strength , leU unnotched | ISO 179 | KJ/m2 | 20 |
| Charpy Impact Strength , leA notched | ISO 179 | KJ/m2 | 1.6 |
| Thermal |
|
|
|
| Heat Distortion Temperature, 1.8Mpa | ISO 75 | ºC | 94 |
| Vicat Softening Temperature, B50 | ISO 306 | ºC | 101 |
| Thermal Expansion Coefficient | ISO 11359 | 1/ºC | 6x10-5 |
| Optical |
|
|
|
| Haze, 3mm | ISO 14782 | % | | Transmittance, 3mm | ISO 13468 | % | 92 |
| Refractive Index, nd | ISO 489 |
| 1.49 |
| Flame Rating, 3mm | UL94 |
| HB |
| Flame Rating, 1.5mm | UL94 |
| HB |
>>
