Spindle type
|
| Mechanical
| High-speed
|
Max Spindle Speed
| rpm
| 6000
| 24000
|
Spindle Power
| Kw
| 2.6
| 3
| 4.5
|
Spindle Taper
|
| BT30
|
Repeat positioning accuracy
| mm
| ±0.01
|
X Axis Travel
| mm
| 400
|
Y Axis Travel
| mm
| 500
|
Z Axis Travel
| mm
| 200
|
Motor Power(X/Y)
| Kw
| 0.75 AC Servo
|
Motor Power(Z)
| Kw
| 1.2 AC Servo
|
Rapid feed rate(X/Y)
| Mm/min
| 35000
|
Rapid feed rate(Z)
| Mm/min
| 25000
|
Cutting feed rate
| Mm/min
| 10000
|
ATC tool number
|
| 8
|
Pneumatic supply
| MPa
| 0.6
|
Collet chuck
|
| ER25
|
Tool DIA. range
| mm
| 1-16
|
Transmission
|
| Taiwan P grade Ball Screw
|
Guide rail
|
| Taiwan High-precision C3 linear guide rail
|
Table size
| mm
| 400*500
|
Max. Load
| Kg
| 200
|
Power supply
|
| 3 phase 380V
|
Weight
| kg
| 2000/2100
|
Machine Size
| Mm
| 1400*1100*2000
|
Packing Size
| Mm
| 1550*1350*2250
|
4th axis (optional)
| Mm
| Φ125
| Φ170
|
