40FT BPW Fuwa Axles Leaf Spring Suspension Cement Bag Transport Side Board Dropside Semi Trailer

Product Details

Product Description

Product Description
40ft BPW FUWA axles Leaf Spring Suspension Cement bag Transport Side Board dropside Semi Trailer

Item	Unit	Quantity	Notice
Overall size			14500*2500mm Detail according to confirmed drawing
Fence	Set	1	0.6m height side board
Axle	Piece	3	13 T axle,Widen brake pad 220mm
Tyre	Piece	12	12R22.5-16PR, without spare tire
Rim	Piece	12	9.0*22.5 Aluminum
Leaf spring	Sets	6	90width*10 pieces*13mm thickness
Braking system	Set		2 line air braking system with air tank ,emergency relay valve,braking chambers and mechanical slack adjusters.
Electrical system	Set	1	24 volt electrical system.7 pin electrical, LED lights, connector.Parking .Stop,reverse,number plate and indicator lights.Rear lights conform to European standard,rear front and side reflectors
Suspension	Set	3	Standard type
Relay valve	Whole vehicle	1	WABCO
Landing gear	Pair	1	Standard 16T, two-speed operation
Kingpin	Piece	1	BAO HUA welded type, 90#
Chamber	Piece		Double T30/30 on rear two axles,T30 on 1st axle
Side beam			140# channel steel 2.5mm)
Floor			1.6mm high-tensile steel plain plate
Cross beam			Square tube 80*40
Upper and lower wing plates			10/10mm
Tool box		1	2.5m/1
Main beam			Main beam500mm,webplate:5mm
Reflectors			Red triangle reflectors at the rear of the trailer and on side
Shotblasting and paint			Chassis is comletely shor blasted to SA 2.5 grade,and painted with first layer of international Zinc Epoxy primer(30 Microns DEF),second layer international high built polyurethane under coat(40 microns DFT),THIRD AND FORTH LAYERS INTERNATIONAL alkyd FINISH TOP coat.Total 80-100 microns. High quality painting
Color			According to your detail RAL code color

The dropside / sidewall trailer is for different kind of cargo long distance transportation, from boxes to bulk cargo. The side panel can be opened, more convenient to unload cargo. This trailers is widely used by transportation companies in the logistics industry. The shape of the side panel can be customized.
1-trailers can be for containers shipping, boxes, bags, steel bars, pipes, and other cargo transportation.
2-Axles number:2 3 4 axles even more.
3-Main beam:500mm height
4-material of the main beam:Q345
5-Suspension:Spring suspension, Rigid, single point, bogie or air suspension
6-Jost landing gear, FUWA axles and Tri-angle tires
7-extendable or sliding type optional
Our dropside trailers advantages:
**Modern design:Double-Groove vertical van, light-weight I beam, arched form longitudinal beams, that make the trailers
Structure super strong and superlight;
**Sound Adaptability:Passed the special processing, the overall frames of the traielrs can stand the actual test of various
Road conditions.
**Superior Material selection:The raw materials are bought from top 5 Steel Mills, and all of other parts are all from top
Suppliers also, like Triangle tyres, Jost landing gear, WEBCO relay valve, we have strict selection requirement for vendors.
**Top configurations:Ensure every trailers with high configurations to decrease the maintaince for clients, and improve the
Trailers with longer service time

---
