| US$12,300.00-14,800.00 | 1 Piece (MOQ) |
| Production efficiency | 160 single peak/Min,160 double peak/Min |
| Peak Height | 38-70mm |
| Peak Width | 24~36mm |
| Wire Diameter | Φ2.5~5.0mm |
| Spring pitch | 16-60 mm |
| Regular spring pitch | 20-30 mm |
| Diameter of spring | 3.0-4.0 mm |
| Power height of S-shape spring | 40-50 mm |
| Cutting type | Adjustable single,double peak |
| Host motor power | 2.2 KW |
| Zig zag spring forming machine motor power | 2.2KW |
| Zig zag spring coiling device power | 0.7KW |
| Punch motor power | 0.37 KW |
| Punch pressure | 1t |
| Ait Consumption | 3-phase 380V 50HZ (can customizable) |
| Total Power | 3KW |
| Machine weight | 1000KG |
