Hot Sale Zoomlion Diesel Mini Changan 3495kg Hook Arm Truck Detachable Garbage Delivery Truck 5030

Product Description

Please note!
The pictures shown as below are new, if you would like a used same model for cheaper price, please contact us for details!
Product DescriptionHot Sale Zoomlion Diesel Mini Changan 3495kg Hook Arm Truck Detachable Garbage Truck 5030
ZBH5030ZXXSCE6 detachable garbage truck (hereinafter referred to as "hook arm truck") is a collection of garbage collection and transportation functions as one of the vehicles. It is composed of two parts of the vehicle chassis and the pulling arm device, and the supporting garbage collection box can be separated from the car body and realize the whole loading and unloading and transfer through the pulling arm device. The garbage bin is placed in every corner of the city by the hook arm truck for the collection of bagged garbage in streets and alleys and communities, and is also suitable for the collection of bulk garbage in narrow areas of roads. The garbage bin can also be used independently as a small collection station for urban garbage. After the garbage collection is full, it is transported to the garbage transfer station by the hook arm truck or directly to the garbage disposal site for treatment. This mode of collection and transportation does not require civil construction, only the ground is flat and solid, the garbage bin is fully sealed, no waste spilling, no odor distribution, and can achieve "one car with multiple boxes", which can reduce investment and operating costs.Function Overview
The main work includes pulling boxes, unloading boxes, garbage transfer, unloading, etc., which is used with our 3 cubic meters garbage can.
Scope of application
This product is mainly used for the transfer and discharge of 3 cubic meters garbage box.
Main structure and performance characteristics
The hook arm car is mainly composed of chassis, pull arm device, hydraulic system, electrical system and so on.

Product Parameters

Item		Unit	Parameter
Vehicle Parameters	Maximum Gross Mass	kg	3495
	Vehicle Weight	kg	1410
	Rated load mass	kg	1955
	Overall dimensions (L×W×H)	mm	4515×1620×1930
	Wheelbase	mm	2990
	Minimum Ground Clearance	mm	175
	Approach/Departure Angle	°	40/34
	Front/rear overhang	mm	725/800
Chassis parameters	Chassis model, category, manufacturer	/	Changan Automobile Class II Chassis SC1031XDD65
	Engine model, manufacturer	/	DAM16KR Harbin Dongan Automobile Power Co.
	Engine displacement	ml	1597
	Fuel consumption limit	L/100km	7.4
	Rated engine power	kW	90
	Maximum net engine power	kW	85
Operation Performance	Pulling operation time	s	≤35
	Unloading operation time	s	≤45
	Unloading cycle operation time	s	≤70
	Self-unloading angle	°	47
	Hook center height	mm	1015
	Outer introduction width	mm	950
	Rated lifting capacity	t	1.5
	Pressure of upper hydraulic system	Mpa	21
	Dumpster volume	m3	3
Driving performance	Maximum vehicle speed (fully loaded)	km/h	100
	Maximum climbing angle	%	30
	Minimum turning diameter	m	11.5

Detailed Photos
The main advantages of the product
1. Superior performance
Strong loading capacity, high working efficiency. With 3 cubic meters of garbage bins, strong loading capacity, belongs to the leading position in the industry. The first cycle time of pulling and unloading operation and the first cycle time of unloading operation are short, and the garbage collection and transportation process is efficient and fast, which belongs to the leading position in the industry.
High reliability of electro-hydraulic system. The hydraulic oil pump takes the force through the force extractor, with sufficient power and high reliability; Key electrical components adopt internationally renowned brands to ensure the reliability of the equipment.
Humanized operation control. The operation control box is installed inside the cab and is very convenient to use and operate. The operator can pull, unload and unload the container without getting off the car.
Good environmental protection. The supporting dustbin adopts a fully enclosed design, and there will be no sewage leakage during the transit, which solves the problem of secondary pollution and is more environmentally friendly.
2. Good quality
High quality key components. The key components of the electrical and hydraulic system are all internationally renowned brands, such as: proximity switches, relays, balance valves, etc., which improves the reliability of the vehicle.
3. Safe and reliable
High security. The main cylinder is controlled by the balance valve, which can control the smooth lifting speed of the main arm and play the role of safety protection; The use of electrical interlock device to improve the safety of equipment operation; The vehicle is equipped with a safety support device. When the vehicle is being repaired, it can lift the pull arm and prop up the safety brace to protect the safety of the maintenance personnel.
FAQ
1. Q: How about the quality of your trucks?
A: Wuhan Ring Valley Environment mainly sells medium and high-end sanitation trucks, no matter the chassis, engine and so on are all belong to the top equipment. Our trucks get ISO 9001: 2008 and CCC, B&V and other related certificates.
2. Q: Is there any advantages of your price?
A: We don't only have new truck but a large selection of used trucks. Different products in different years are available at different prices. We'll be sure to help you find the best vehicle in suitable price.
3. Price term: FOB, CIF.
4. Payment: 30% deposit after order confirmation, 70% balance should be paid before delivery. All are by T/T, L/C.
5. Delivery time: 7-20 working days after payment is received.
6. Standard Steering: Left-hand drive, if you need Right-hand drives, please inform us, we will make special order for you.
If you have any other questions, please feel free to contact us at any time.

---
