Basic Info.
Model NO.
CD6140, CD6150, CD6166, CD6180
Processing Accessory
Chuak Manual Lathe
Guide Rail
Horizontal Guide Rail
Controlling Mode
Servo Motor
Automatic Grade
Semiautomatic
Certification
CE, ISO 9001
Product Name
Semi Auto Lathe Machine
Used as
Manual Lathe Machine
Max.Swing Over Bed
400/500/660/800
External Dia.of Square Tool
25*25
Specification
CD6140/CD6150/CD6166/CD6180
Production Capacity
1000PCS/Year
Product Description
Manual Machine and Semi Auto Electronic Lathe Engine Lathe Traditional Conventional Turning
Semi Auto Electronic Lathe Feature:
1.Electronic lathes are fully functions as engine lathes;
2. Fixed length machining function can be realized , without fast motor;
3. Can realize straight thread machining with arbitrary pitch ;
4. More convenient operation, greatly reduce the operator labor intensity.
Specification:
| Specification | unit | CD6140 | CD6150 | |
| Max.swing over bed | mm | 400 | 500 | |
| Distance between centers | mm | 1000/1500 | 1000/1500 | |
| Distance from spindle center to guide rail plane | mm | 220 | 250 | |
| Max.swing over cross slide | mm | 230 | 290 | |
| Dia. Of chuck | mm | 200 | 250 | |
| Spindle nose | mm | C6 | D6 | C8 | D8 |
| Spindle bore | mm | 58 | 82 | |
| Spindle speeds | 3 shifts stepless | 20-2000 | 16-1600 | |
| X rapid speed | M/min | 3.3 | 3.3 | |
| Z rapid speed | M/min | 6.5 | 6.5 | |
| X travel | mm | 270 | | |
| Z travel | mm | 1000/1500 | 1000/1500 | |
| Dia. Of tailstock | mm | 75 | 75 | |
| Tailstock travel | mm | 160 | 160 | |
| Tailstock taper | | MT5# | MT5# | |
| Tool post type | | 4-station | 4-station | |
| External Dia.of square tool | mm | 25*25 | | |
| Overall dimensions | mm | 1000:2440*1230*1740;
1500:2940*1230*1740. | 1000:2440*1230*1740;
1500:2940*1230*1740. | |
| weight | kg | 1000:2100;1500:2150 ; | 1000:2190;1500:2250. | |
1)DELIVERY TIME: 45 DAYS AFTER RECEIVING DEPOSIT
2)PARKING: IN WOODEN CASE OR CARTONS
3)INSURANCE: ALL RISKS BY BUYER
4)PAYMENT: 30%T/T IN ADVANCE, 70% T/T 5 DAYS BEFORE SHIPMENT
5)SHIPMENT: BY SHIP
6)GOODS ARE ORGIN OF CHINA
7)THE PRICE IS VALID FOR 2 MONTHS.
TENGZHOU ALLWAY MACHINERY CO.LTD.
Always create value for customers. Develop together with customers!
>>
