Stainless Steel Ribbon Mixer for Powder and Granule Blending

Product Description

The Horizontal Ribbon Mixers are essential for the seamless mixing, stirring, and blending of powders, granular materials, slurries, or viscous substances. These mixers offer the flexibility of being equipped with a liquid spraying system and can be tailored to user specifications to function under vacuum, pressurized, heated, or cooled conditions. This remarkable versatility ensures that the mixing and stirring needs of materials are met under a wide array of process conditions. Horizontal ribbon mixers are extensively utilized across industries such as chemical, pharmaceutical, food, and building materials. They are adept at mixing powder with powder, integrating powder with a small quantity of liquid, and blending powder with granules.
The Horizontal Ribbon Mixer is primarily composed of a robust mixing chamber and an efficient stirrer drive device. Within the U-shaped tubular chamber lies a dual-layered, counter-rotating ribbon spiral agitator shaft. The outer spiral ribbon, powered to perfection, propels materials from the ends of the U-shaped chamber towards the center, while the inner spiral ribbon moves materials from the center towards the ends, orchestrating a dynamic convective mixing effect. The strategically positioned discharge port is centered at the bottom of the horizontal chamber. The ingeniously crafted spiral structure of the outer ribbon, working in harmony with the rotation direction of the main shaft, deftly channels the material within the chamber towards the central discharge port, ensuring an efficient discharge process devoid of dead corners.
Product Features
1. Cantilever Shaft Structure, engineered so that the bearings' end remains untouched by the material.
2. The minimal gap between the agitator blades and the container wall is precision-designed to eliminate material adhesion.
3. A standardized agitator drive box guarantees consistent equipment performance and minimizes maintenance expenditure.
4. Easy-Cleaning: Expertly designed for quick and comprehensive cleaning between batches;
5. Durable Construction: Engineered with high-grade materials to ensure long-lasting reliability;
6. Wide Application: Versatile across a multitude of industries, including pharmaceuticals, food processing, chemicals, and cosmetics.
Technical Parameters

Product Model	RX-LDH-0.3	RX-LDH-0.5	RX-LDH-1	RX-LDH-2	RX-LDH-3	RX-LDH-4	RX-LDH-5	RX-LDH-6	RX-LDH-8	RX-LDH-10	RX-LDH-15	RX-LDH-20	RX-LDH-30
Effective Volume (m3)	0.18	0.3	0.6	1.2	1.8	2.4	3	3.6	4.8	6	9	12	18
Maximum Batch Output (kg)	200	300	600	1200	1800	2500	3000	3600	4800	6000	9000	12000	15000
Rotation Speed (r/min)	62	62	49	33	33	27	27	27	22	22	14	14	12
Drive Power (kW)	5.5	7.5	11	15	18.5	22	30	37	45	55	75	90	110
Equipment Weight (kg)	600	900	1200	2000	2500	3500	4000	4500	5000	6000	7500	10500	13000
Length	2280	2670	3140	3860	4460	4950	5280	5530	2100	5610	5820	6300	7000
Width	680	780	980	1200	1300	1400	1550	1560	1720	1750	2000	2350	2600
Height	880	1240	1400	1650	1700	2000	2100	2200	2500	2650	2900	3160	3350

Product Display
Product Structure
Application
The Double Cone Mixer can be effectively applied in sectors like powder metallurgy, electrical alloys, magnetic materials, battery powders, pearlescent pigments, chemical industry, medical, and food industry.
About Our Company
Shijiazhuang Rongxin Science and Technology Co., Ltd.
was established in 2007, with its headquarters nestled in Shijiazhuang, the vibrant capital city of Hebei Province. Our company specializes in the design and provision of material handling automation systems. We are proud to be recognized as a leader in our field, with numerous patents and accolades, including prestigious titles such as "National High-Tech Enterprise" and "Innovative Enterprise."
At Shijiazhuang Rongxin Science and Technology Co., Ltd, we proudly offer a diverse array of advanced solutions including our dust-free enclosed feeding systems, sealed conveying systems, pneumatic conveying systems, and tube chain conveying systems. These cutting-edge systems are integral across various industries such as metal materials, food processing, chemicals, pharmaceuticals, and the burgeoning new energy sector, delivering efficiency and reliability. Moreover, we take tremendous pride in owning and managing our own state-of-the-art production facility. Our mature manufacturing lines are a testament to our commitment to excellence, ensuring that every piece of equipment meets and surpasses industry quality standards.
