Ozone UV Lamp Single-End 4 Pins 10W/14W/17W High Quality

Product Description

uv lamp, 17w uvc germicidal lamp, Ozone uv lamp
Specification:
The average rated life is 10000 hours ceramic lamp set, antioxidant,radiation protection Different diameter of lamp by customer's request. All made of high quality quartz glass. Very high reliability and stability OEM & ODM acceptable Single and Double Pin,H type, U-type etc. Lamp Cap: G23,2G7 Ozone and Ozone-free choose
Description
Ultraviolet sterilization is the irradiation of ultraviolet rays, which destroys and changes the DNA (deoxyribonucleic acid) structure of microorganisms, so that the bacteria immediately die or cannot reproduce the offspring and achieve the purpose of sterilization. The true bactericidal effect is UVC ultraviolet light, because the C-band ultraviolet ray is easily absorbed by the DNA of the living body, and the ultraviolet ray of about 253.7 nm is optimal.
UV germicidal lamps with different bases, diameters, and lengths are available, which offer excellent efficiency. We supply two types of UV lamps, emitting UV-C wavelength at 253.7nm, ozone-free; while emitting UV-C wavelength both at 253.7nm and 185nm, ozone-generating.

Single-end 4pin UV Germicidal Lamp
Lamp Type	Tube Diameter	Length	Lamp Power	Lamp Current	Lamp Voltage	254nm UV output @1M	Average Life
	mm	mm	W	mA	V	μm/cm²	Hours
ZW10D15W-Z212	15	212	10W	425	22-39	21-24	8000
ZW14D15W-Z287	15	287	14W	425	28-39	31-35	8000
ZW15D15W-Z303	15	303	15W	425	30-40	33-37	8000
ZW17D15W-Z356	15	356	17W	425	34-46	48-54	8000
ZW23D15W-Z436	15	436	23W	425	40-55	62-69	8000
ZW28D15W-Z550	15	550	28W	425	51-69	85	8000
ZW37D15W-Z793	15	793	37W	425	78-101	110	8000
ZW40D15W-Z842	15	843	40W	425	81-99	120-130	8000
ZW55D15W-Z1149	15	1149	55W	425	122-149	150-180	8000
ZW75D15W-Z1554	15	1554	75W	425	173-210	180-210	8000
ZW80D19W-Z846	19	846	80W	800	120	240-270	8000
ZW120D19W-Z1149	19	1149	120W	800	170	330-380	8000
ZW150D19W-Z1554	19	1554	150W	800	220	400-450	8000
ZW240D19W-Z1554	19	1554	240W	1800	190	650-680	8000
ZW320D19W-Z1554	19	1554	320W	2200	180	800-830	8000

Remark: No o-ozone, ozone and high ozone uv lamp;
G10q/2G11 Lampholder;
Can be customized the power and length based on customer requirements;

Double-end 2pin UV Germicidal Lamp
Lamp Type	Tube Diameter	Length	Lamp Power	Lamp Current	Lamp Voltage	254nm UV output @1M	Average Life
	mm	mm	W	mA	V	μm/cm²	Hours
ZW4S15W-Z135	15	135	4W	160	18-24	12	8000
ZW6S15W-Z212	15	212	6W	160	36-48	18	8000
ZW8S15W-Z287	15	287	8W	145	48-64	28	8000
ZW10S15W-Z331	15	331	10W	220	55-70	30	8000
ZW15S15W-Z437	15	437	15W	300	59-71	44	8000
ZW20S15W-Z589	15	589	20W	320	71-91	75	8000
ZW20S19W-Z589	19	589	20W	320	68-84	75	8000
ZW30S19W-Z894	15	894	30W	300	112-132	107	8000
ZW30S25W-Z894	19	894	30W	300	112-132	107	8000
ZW40S19W-Z1199	15	1199	40W	330	120-140	117	8000
ZW40S25WZ1199	19	1199	40W	330	110-130	117	8000

H-type UV Germicidal Lamp
Lamp Type	Tube Diameter	Length	Lamp Power	Lamp Current	Lamp Voltage	254nm UV output @1M	Average Life
	mm	mm	W	mA	V	μm/cm²	Hours
PLS 5W	12mm	107/85	5W	180	30-40	14	8000
PLS 7W	12mm	137/115	7W	175	42-62	16	8000
PLS 9W	12mm	167/145	9W	170	54-66	23	8000
PLS 11W	12mm	237/215	11W	155	81-99	38	8000
PLS 13W	12mm	186/164	13W	300	48-62	40	8000

PLL 18W	17mm	217/195	18W	375	52-64	57	8000
PLL 24W	17mm	317/295	24W	345	77-97	94	8000
PLL 36W	17mm	411/379	36W	435	98-118	147	8000
PLL 40W	17mm	533/501	40W	385	130-150	155	8000
PLL 55W	17mm	533*501	55W	550	110-130	170	8000

Remark: No-ozone, ozone and high ozone uv lamp;
G23,GX23,2G7,2G11,G32q Lampholder;
Can be customized the power and length based on customer requirements;
Application
Air purifiers, disinfection cabinets, microwave ovens and air conditioners etc.
Sterilization of air and objects on schools, hotels, restaurants, homes, and offices etc.
Related Product: Mached uv ballast
Specification: DC12V/DC24V, AC110V/AC220V/AC100-240V

---
