Welcome to visit

High Speed ABA Three Layers HDPE LDPE PLA Biodegrdable Shrink Plastic Film Blowing Machine

US$15,000.00
1-2 Sets
US$14,000.00
3-4 Sets
US$13,000.00
5+ Sets

Basic Info.

Type
Multi-Layer Co-extrusion Film Blowing Machine
Raw Material
PE
Maximum Folding Width of Film
600-1000mm
Screw Diameter
50*2/55*2
Automation
Automatic
Computerized
Computerized
Machine Weight
4T
Certification
CE, ISO9001:2008
Screw
Bimetalic High Speed Screw
Die Head.
ABA Three Layers
Speed
100-120kgs/H
Rewinder
Automatic Cutting and Change Roll
Transport Package
Standard Wooden Box, etc.
Specification
CE, ISO
Trademark
SANBI
Origin
China
HS Code
8477301000
Production Capacity
100-120kgs/H

Product Description

High speed ABA Three Layers HDPE LDPE PLA Biodegrdable Shrink Plastic Film Blowing Machine
Use:
The lines are designed developed by our corporation according to market need, they reach the advanced levels in the 90s, come up with analogous lines in home.
It is optimum designed on the trounds of preference of analogous lines in foreign and home.
SPECIFICATIONS
Model ABA 800
Screw Diameter Ф50×2
Screw Ratio L/D 30:1
Screw Speed 15-120r/min
Main Motor Power 15Kw×2
Extrusion Output 100-120kg/h
Range of Die ABA Ф80
Single-sided Thickness of Film 0.01-0.10mm
Max. Folding Width of Film 800mm
Electric Total Capacity 50Kw
Overall Dimension 5000×3500×5000mm
Weight of Machine 4T

Machine Pictures:
