Hot Sale Planetary Concrete Mixer 1000L Concrete Planetary Mixer Machine Suppliers

US$10,000.00
1-2 Sets
US$9,800.00
3-9 Sets
US$9,200.00
10+ Sets

Basic Info.

Type
Concrete Mixer
Shotcrete Type
Dry
Machining Process
Welded Molding Machine
Structure
Rotor Type
Productivity
180m²/h
Feeding Height
1390mm
Vibrating Amplitude
2.4mm
Certification
ISO9001: 2000, CE
Condition
New
Color
Accordingly
Name
Planetary Concrete Mixer
Item/Type
MP 500
out Capacity(L)
500
Input Capacity(L)
750
out Weight(Kg)
1200
Mixing Power(Kw)
18.5
Lifting Power(Kw)
4
Planet/Blade(Nr) One Mixing Shaft with T
2
Side Scraper(Nr)
1
Discharging Scraper(Nr)
1
Weight(Kg)
2400
Dimension (L*W*H, mm)
2230*2080*1880
Transport Package
Laminated Packaging
Specification
accordingly
Trademark
SDCAD
Origin
China
HS Code
8474900000
Production Capacity
5000 Sets/Month

Product Description


Mixing Locus Diagrams This diagrams show the perfect mixing action of the DEX planetary mixer from 5 to 60 seconds after material is added. Note that the floor is completely swept by the mixing stars action every 4 revolutions (6 seconds) and that each zone is covered at regular intervals in time.

PRODUCT SPECIFICATIONS
Model
 MP330
 MP500
 MP750
 MP1000
 MP1500
 MP2000
 MP2500
 MP3000
Output Capacity (L)
330
 500
 750
 1000
 1500
 2000
 2500
 3000
Input Capacity (L)
500
 750
 1125
 1500
 2250
 3000
 3750
 4500
Input Mass (kg)
800
 1200
 1800
 2400
 3600
 4800
 6000
 7200
Mixing Power (kw)
15
 18.5
 30
 37
 55
 75
 90
 110
Discharge Power (kw)
2.2
 2.2
 2.2
 3
 3
 4
 4
 4
Lifting Power (kw)
4
 4
 7.5
 11
 15
 22
 --
 --
Skipper Capacity (L)
580
 870
 1300
 1740
 2610
 3480
 --
 --
Skipper Mass (kg)
870
 1305
 1950
 2610
 3615
 5220
 --
 --
Skipper Speed (m/s)
0.25
 0.25
 0.25
 0.25
 0.25
 0.25
 --
 --
Weight (kg)
1700
 2000
 3500
 6000
 7000
 8500
 10500
 11000
Dimension (mm)
1910 * 1590* 1747
 2220* 2071* 1880
 2581* 2336 * 2195
 2891* 2602* 2217
 3223* 2902* 2425
 3625*3230* 2630
 2893* 3550* 2695
 3893* 3550* 2975
