2023 Torch High Power Laser Conveyor Vacuum Furnace V8l with Low Price in China

Product Description

2023 Torch High Power Laser Conveyor Vacuum Furnace V8l with Low Price in China
Technical Data of Vacuum Reflow Soldering System V8: 1. Significantly reduce the welding bubbles in the solder, making the void rate as low as 1-2%.
2. Improve the electrical performance of the product and the welding joints, effectively improving the reliability of the welding point and the welding quality.
3. It can be used for double-sided welding of PCB, suitable for mass production, and can be continuously put into the production line. The production cycle is controlled at an average of 30-60S.
4. The degree of vacuum, vacuum holding time, deflation time, vacuum rate, etc. can be set freely.
5. The circuit board with aluminum heat sink can be welded.
6. Low power consumption and high heat insulation design based on the concept of environmental protection. The case temperature does not exceed 40 degrees.
7. High-efficiency and large-capacity flux recovery device.
8. Use integrated oxygen sensor technology to ensure precise control of oxygen content, and real-time/continuous monitoring of residual oxygen content in the furnace.
9. The equipment can be used as an ordinary nitrogen or air furnace at the same time.
Technical Data of Vacuum Furnace V8L

(Required)	Technical specifications	model: V8L
		Actual index value
Actual index value	length	MAX 400mm
	width	MAX 450mm
	height	MAX 30mm
Performance parameter	heating method	Hot air heating
	Speed adjustable range	≥20cm/min
	Max. heating temperature	MAX 350ºC
	heating temperature	<200ppm
	Heating rate range	1-3ºC/s
	Heating rate range	1-3ºC/s
	The temperature of the baked product	80ºC
	Heating rate range	±4ºC
	Number of equipment temperature zones (heating)	8+1
	Number of equipment temperature zones (Cooling)	2
	Warm-up time (heating time)	According to the specific requirements of the process
	Oil pump meets the demand of clean room/class 10,000	Class 10,000
	Class 10,000	≤2mbar
Dimension/Weight	Dimension (m)	6.3m(L)*1.55m(L)*1.7m(H)
	Weight (Kg)	1600kg
Power	Voltage	380V
	Frequency	50Hz
	Power Consumption	Maximum power 32KW Average power 10KW
	UPS	Optional
Forming Gas/N2	Connector Diameter	10mm
	Pressure	0.3MPa-0.6MPa
	Nitrogen consumption	300L/min
	Flow Rate	80psi(0.5Mpa, gas flow rate 80L/M)
Compressed Air	Connector Diameter	10mm
Pressure	0.3MPa-0.6MPa
Flow Rate	80psi(0.5Mpa, gas flow rate 80L/M)
Exhaust	Exhaust Flow	MAX 8L/s
Cooling Water	Connector Diameter	10mm
	Flow Rate	Instantaneous maximum 18L/s
Instantaneous maximum	Delivery cycle/week	60 days
	Can the delivery be delayed when the on-site installation conditions are not met	Yes
Technical support, training requirements	The response time for troubleshooting at the site is within 48 hours, and training is included.	Arrive at the site for 24 hours, and installation training is included.

---
