Automatic Liquid Spouted Pouch Filling Capping Machine for Jelly Milk Detergent Shampoo

Product Description

Product Description Automatic liquid Spouted Pouch Filling capping Machine for jelly milk detergent Shampoo is especially made for automatic liquid, juice, milk, liquid detergent, maundry detergent, shampoo lotion or paste packaging of various premade spouted bags, spouted pouches or spouted doypacks, which can auto finish pouch feeding, pouch quantitative servo filling, cap-feeding & servo capping & bag conveying out, widely used in foodstuff, drinks, chemicals & cosmetics fields.
Main structure & process:
1.Pouch hanging & feeding
2.Servo Piston filling, with high fillingccuracy, suitable for both foamy liquids and non-foamy products; no bag no filling,
(filling can be servo piston, or servo pump filling depends on materials to be filled)
3. Cap unscrambling & cap feeding
4.servo capping, with wide application, adjustable capping torqure, & perfect capping quality
5.Pouch exiting conveying belt Detailed Photos spouted pouches 2-head servo filling capping monoblock (high-performance, highly-efficient & cost-effective) quality horizontal servo filler, universal, fast, accurate & easy to wash, maintain
Milk Juice jam sauce lotion oil liquid cleaner spoutedf pouch filling capping machine with servo filler fyi
spouted pouches 2-head liquid jam sauce filling capping monoblock (high-performance, highly-efficient & cost-effective)
fully-auto 4-head liquid/cream spouted pouch servo filling capping monoblock
spouted pouche liquid paste filling capping machine, professionally customize for different materials, speed, bags
Main parameters:

Model	BNAFC-PR1	BNAFC-PR4
Filling scope	100-1000ml; 500-3000ml (customize)
Filling nozzle	1 nozzle (can be 2-nozzle)	4 nozzles
Capping head	1 head	4 heads
Filling principle	Servo Piston filling (based on different products to be filled, can be servo pump filling etc)
Capping	Servo capping (magnetic capping based on caps)
Cap/bottle size	Based on the actual samples
Capacity	15-20BPM	45-55BPM
Filling precision	≤±1%
Air pressure	0.5~0.7MPa
Voltage	220V 50/60HZ 1P

Company Profile
Welcome to contact for mor details and visit us in Guangzhou China :)
Similar series for bag packaging machines reference:
auto 1nozzle spouted pouches filling capping machine with acrylic glass hood & safety door fyi
Auto liquid cleaner/detergent/oil 4-head filling capping packing machine with acrylic glass hood fyi
Pouch/doypack liquid filling can be priming type; also filling can be designed with hopper for auto gel/paste/cream and equipped with material pump feeding for higher production efficiency

---
