1325 Excellent Quality Mrble Slab Cutter Granite Automatic CNC Cutting 1325 CNC Stone Engrave Machine

Product Description

1325 Excellent Quality Mrble Slab Cutter Granite Automatic cnc Cutting 1325 Cnc Stone Engrave Machine:
This machine is mainly for Granite Engraving, it can make the letters and different nice pictures on stone. It's of Hyanid Servo Motor Drive, High Precision bevel Drive, and the Screw is of Taiwan TPI2505.lt uses the Mono-block structure, with special back installation, Steel structure, and the surface with electroplating treatment.
lt can do the Automatic Oil filling, completely elcosed Dustproof.

Machine Details
No.	Part	Details
1	Machine Structure	Heavy square pipe welding, aging treatment
2	X axis Traveling Area	1300mm
3	Y axis Traveling Area	2500mm
4	Z axis Traveling Area	600mm
5	Transmission	Z axis Taiwan Ball Screw and XY axis gear Transmission
6	Guide Rail on X Y Z axis	Square guide rail, 25mm
7	Table	Stainless steel water tank table
8	Drive & Inverter	Stepper motor & drivers
9	Spindle Power	5.5kw rotate spindle*2
10	Software	Type3, Artcam Ucancam
11	Control System	NC Studio control system
12	Electric Box	Large independent electric box
13	Voltage	3-phase 380V 60Hz

Technical Specification
No.	Model	1325
1	Spindle Power	5.5kw
2	Spindle Speed	0-24000RPM
3	Working Area	1300*2500mm
4	Z-axis Height	600mm
5	Travelling Positioning Accuracy	±0.03/300mm
6	Positioning Accuracy	±0.03mm
7	Max. Rapid Travel Rate	33000mm/min
8	Max. Working Speed	24000mm/min
9	Computer Interface	USB
10	Command Language	G Code
11	Working Voltage	3-phase 380V 60Hz
