| Type | HD 20x Multi-interface Camera |
| Image Sensor | Sensor | 1/2.8" Progressive CMOS |
| Effective Pixel | 2.0 Megapixel |
| Min. Illumination | 0.5 Lux at F1.6 |
| White Balance | AUTO/MANUAL/INDOOR/OUTDOOR/ATW/MANUI |
| Gain Control | AUTO |
| Back-light Compensation | On/Off |
| Shutter | 1/11/30000 |
| S/N Ratio | >50db |
| Lens | Focus | f=5.9-106.2 mm F1.8-3.9 |
| Iris | F1.6-F9.6 |
| Zoom | 18x optical zoom |
| HOV | 56°-4° |
| Video Output | 3G-SDI, USB2.0, LAN,DVI-I (DVI-I change to HDMI,YPbPr) |
| Video Output Format | 1080p60/50/, 1080i60/50, 720p60/50/30/25 |
| Communication Interface | RS232C, RS485 (bidirectional) |
| Communication Protocol | VISCA, PELCO-D |
| Baud Rate | 2400/4800/9600/38400bps |
| Tour Path | 1 |
| Preset Position | 256 |
| 256 Speed Match | Speed can be determined by the zoom in/out of the lens |
| OSD Menu | Support |
| Image Flip | Support |
| Pan Movement Speed | 100°/S |
| Tilt Movement Speed | 72.2°/S |
| Pan Movement Angle | 355° |
| Tilt Movement Angle | 90°(up), 30°(down) |
| Auto Scan | Support |
| Boundary Scan | 0-355°(programmable) |
| Remote Control | IR wireless P/T/Z |
| Power Supply | DC12V±10%,2A |
| Working Temperature | 50ºC |
| Working Humidity | 0-95% RH |
| Dimension (LxWxH) | 250mm×140mm×154mm |
| Net Weight | 1400g |
