High Capacity Pst Standard Industrial Pipeline Centrifugal Pump for Wastewater Treatment

Product Description

High Capacity PST Standard Industrial Pipeline Centrifugal Pump For Wastewater Treatment Product Description
Product overview
The PST Standard Pipeline Centrifugal Pump (hereinafter referred to as the electric pump) is a new-generation product designed in accordance with the performance parameters specified in the enterprise standards and combined with the many years of production experience of our company. The pump features a compact structure, small size, beautiful appearance, small installation footprint, stable operation, long service life, high efficiency, low power consumption, and convenient installation. It can also be used in series or parallel according to the requirements of head and flow rate. This electric pump consists of three parts: an electric motor, a mechanical seal, and a water pump. The motor is a single-phase or three-phase asynchronous motor. A mechanical seal is adopted between the water pump and the electric motor. The rotor shaft of the electric pump is made of high-quality carbon steel material and has undergone anti-corrosion treatment to ensure more reliable mechanical strength of the shaft, which can effectively improve the wear resistance and corrosion resistance of the shaft. Meanwhile, it is also convenient for the maintenance and disassembly of the impeller. "O"-shaped rubber sealing rings are used for static sealing at each fixed spigot sealing position of the pump.
Scope of use
1. It is applicable to urban environmental protection, greenhouse sprinkler irrigation, construction, fire protection, chemical industry, pharmaceutical manufacturing, dye printing and dyeing, brewing, electric power, electroplating, papermaking, petroleum, mining, equipment cooling, etc.
2. It can be used in conjunction with filter presses of any model and specification, and is the most ideal matching pump type for sending slurry to the filter press for filtration.
Product Parameters

Maximum flow rate	220MH
Maximum head	95M
Maximum suction stroke	7M
Temperature of the extracted liquid	-10 ºC -90 ºC
Environmental temperature	-10 ºC -40 ºC
Maximum operating pressure	10BAR (PN10)
Motor allows continuous long-term operation	S1

Technical data
Detailed Photos
FEATURES
The dimensions of the pump casing comply with EN733. The pump casing is made of cast iron material. The flanges for connection are also made of cast iron and conform to ISO 228/1.
Impeller: Made of cast iron or stainless steel.
Motor: With F-class insulation grade
IP54 protection grade. Company Profile
Lundu Electromechanical Co., Ltd. is a collection of production, sales, scientif ic research, import and export and after-sales service as one of the high-tech enterprises. The company speciaizes in the production of YE3, YE4, MS, YS, YE) series of single, three-phasemotor; Aluminum motor, frequency conversion motor and other special motor.The company strictly in accordance with the ISO9001 international quality system certif ication management production, so that the speed of new product development and success rate is greatly improved, the company has advanced production, factory in spection equipment, so that the product quality is strongly guaranteed, so that it has won the trust and praise of a wide range of users. We face the future market with continuous innovation. Our products are exported to Europe, America, Africa, Southeast
Asia, Middle East and other countries and regions. FAQ
1.Are you a trade company or a manufacturer?A:We are an ISO, approved manufacturer specialized in water pump. OEM & ODM service are available. 2.What is your MOQ?A: Our minimum order quantity is 100 piece. 3.What is your delivery date?A: The delivery date is about 5-15 days after receipt of payment. 4.What is your payment terms?A: 30% deposit in advance and 70% balance before shipment. 5.Do you inspect the finished products?A: Yes, each step of production and finished products will be came out inspection by QC department before shipping.

---
