630X700mm Table Size CNC Horizontal Machining Center Hmc630 Milling Machine Tool

Product Description

Product Description
Products Description:
HMC500 CNC milling machine horizontal machining center
Main configuration & accessories:
Taiwan Shangyin ball screw and precision screw lock nut
Taiwan Shangyin roller linear guide, xy55 roller, z55 roller
Taiwan BT50 spindle unit
Standard single-station rotary table, optional double-station interchange table.
X, Y, Z three-axis stainless steel guide rail internal protection
Standard configuration Taiwan Okada 24T manipulator disc tool magazine
Equipped with automatic lubrication system, cooling, spindle air blowing, warning lights, explosion-proof lighting, etc.
The standard configuration is all metal outer protection.
Equipped with double spiral conveyor Product Parameters
Technical parameter:

		HMC630	HMC630/1	HMC630/2	HMC630/3
		Single table	Double table	Continuous indexing single table	Continuous indexing double table
Worktable	Worktable size	630×700mm	630×700mm	630×700mm	630×700mm
	Worktable number	1	2	1	2
	Worktable indexing	1°X360	1°X360	0.001°	0.001°
	Worktable transmission	240	240	160	160
	changer worktable transmission	/	240	/	240
	Changer worktable structure	/	Rotary type	/	Rotary type
	Changer worktable time	/	24s	/	24s
	Worktable loading capacity	950kg	950kg	950kg	950kg
	Max. Swing diameter of workpiece	¢1100mm	¢820mm	¢1100mm	¢820mm
Travel	Worktable movement left and right(X Axis)	1050mm	1050mm	1050mm	1050mm
	Spindle head movement up and down(Y Axis)	750mm	750mm	750mm	750mm
	Column movement forward and backward (Z Axis)	900mm	900mm	900mm	900mm
	Distance from spindle center to worktable surface	120~870mm	0~750mm	120~870mm	0~750mm
	Distance from spindle nose to worktable center	130~1030mm	130~1030mm	130~1030mm	130~1030mm
Spindle	Max. Spindle speed	6000rpm	6000rpm	6000rpm	6000rpm
	Spindle taper	BT50-190	BT50-190	BT50-190	BT50-190
	ATC	24 (30/40)	24 (30/40)	24 (30/40)	24 (30/40)
Motor	Spindle motor	15kw	15kw	15kw	15kw
	X,Y,Z axis servo motor	22/30/30 Nm	22/30/30 Nm	22/30/30 Nm	22/30/30 Nm
	B axis servo motor	8 Nm	8 Nm	12 Nm	12 Nm
	APC servo motor	/	8 Nm	/	8 Nm
Leadscrew (Taiwan)	X axis, Y axis(Diameter×Pitch)	40×12	40×12	40×12	40×12
	Z axis(Diameter×Pitch)	50×12	50×12	50×12	50×12
Rapid speed	X , Y, Z axis	24m/min	24m/min	24m/min	24m/min
	B axis	10r/min	10r/min	10r/min	10r/min
Positioning accuracy	X , Y, Z axis	0.01	0.01	0.01	0.01
	B axis	10″	10″	10″	10″
Repositioning accuracy	X , Y, Z axis	0.006	0.006	0.006	0.006
	B axis	5″	5″	5″	5″
Machine overall dimensions		3010×2690×2485	4225×2690×2485	3010×2690×2485	4225×2690×2485
Machine net weight		100000kg	11000kg	10000kg	11000kg

Standard Accessories:
Fanuc 0i-MF (5) controller
24 Tools disc type magazine
BT50 Taiwan spindle
Spindle speed 6000rpm belt type
2 *chip conveyor (Screw type)
1 *chip conveyor & chip bucket (Chain type)
Full closed cover
Automatic lubrication
Coolant system
Work lamp
Tri-color indication lamp
Air gun
Water gun
Air conditioner in cabinet
3-Axis linear guideway from Hiwin or PMI
Ball leadscrew from Hiwin or PMI Company Profile
