| US$290.00-300.00 | 1 Piece (MOQ) |
| Product Type | DX-35 |
| Stroke | 120mm |
| Magnetic base bize | 167*84*44mm |
| Input power | 1100W |
| The max cutting depth | 50mm (2") |
| The max cutter capacity diameter | 35mm (1-3/8") |
| Motor can adjust the height to | 95mm |
| The max diameter of twist drill | 13mm |
| The min cutter depth | 10mm |
| Magnetic adhesion | 10000N |
| The type of shank | 19.05mm (3/4") |
| Total weight | 15.4kg |
| Load speed | 450rpm |
| Countersunk drilling | 10-35mm |
| 1. | Tilt protection design for motor air Inlet avoid liquid or debris falling into the inside of the motor. |
| 2. | Two-way sliding rails: special process of Hard wear-resisting, makes the wear-resisting performance increased more than 2 times, Is the guarantee of lower supplies. Two-way sliding rails, which make the motor height be adjustable according to the different requirement. Stroke up to 210mm. Rail positioning function, which can make the motor stop at any position to prevent self-rig decline and damage cutter. |
| 3. | Design of internal self-lubricating function ensure longer life of gear. |
| 4. | Automatic internal cooling system, external cooling ring design to prevent water overflow into the gear box, the overall design makes the appearance more beautiful. |
| 5. | Design of overall aerial lifting holes and insurance rope holes guarantee double protection for the safety of the aerial personnel and equipment. |
| 6. | Design of overall tilt body ensures its overall rigidity, and improve drilling accuracy. |
| 7. | Magnetic bottom wear design, which delays the wear of magnet bottom and extend service life. Magnetic base with maximum adhesion up to 10000N ensures the safety and reliability during drilling operations. |
