Naked Cable Accessories, Bare Terminal Connector

Product Description

Spade insulated terminals
1, cable lugs are suitable for the connection of copper conductors (section 1.25-8mm2) in power cable with electronic equipment
2, Material: They are made of higher 99.99 % pure copper tube T2.3, Working temperature -55oC-150oC
4, Surface: Tin-plated
5, Insulated material: PVC, nylon
6, Wire specification/rated: According customer required
7, Attribute: Pre-insulated, blade shape
The company has more than 95% of the full automatic production lines, nissan 200 tons, production capacity continues to adjust and expand, to meet the challenge of the market at any time.
Through the European CE safety certification, American UL safety certification, the company has a SC Japan JIS standard, the German DIN standards, AWG American standards, etc.
Companies always adhere to: quality first, service first, from raw materials into the factory inspection, process inspection to every working procedure, outbound packaging cengcengbaguan .
Company has own copper pipe, copper strip, copper platoon of raw material processing factory, with strong competitive advantage price on equal quality to every guest get the maximum benefits.

PART NO	ITEM NO	DIMENSIONS
		ΦD	Φd	B	L	W	H	T
LY0028-1001	KS10-12NL	9.0	4.5	15.5	29.5	4.3	2.4	1.1
LY0028-1002	KS16-13NL	10.5	5.9	19.0	35.0	5.5	2.6	1.2
LY0028-1003	KS25-15NL	11.5	7.0	24.5	44.5	6.8	2.6	1.2
LY0028-1004	KS35-20NL	14.0	8.7	29.5	54.0	8.0	3.2	1.5
LY0028-1005	KS50-20NL	15.8	9.8	35.0	61.0	9.5	3.8	1.8
LY0028-1006	KS70-25NL	18.0	11.6	44.0	75.0	11.0	4.2	2.0
LY0028-1007	KS95-25NL	21.6	13.7	44.0	75.0	12.5	5.2	2.5

---
