Small glass cutting machine/ultra-thin glass cutting machine

Product Details

Product Description

Product Description
glass cutting machine
Machinable glass size (mm): 1200 * 1200, or customized equipment according to customer needs!
Equipment specifications: Customized equipment according to customer needs!
Cuttable glass size: 1200x1200 (cutting table according to equipment)
Workbench height: 900 ± 50mm
Cutting thickness: 1-19mm
Parallelism of straight lines: ≤ ± 0.2mm/m
Diagonal accuracy: ≤ ± 0.2mm/m (the above accuracy is subject to the accuracy of the cutting line before breaking the sheet)
Cutting bridge speed: 0-180m/min (adjustable)
Cutting bridge acceleration ≥ 3.0m/s2
Blade holder speed ≥ 150m/min
Blade holder acceleration ≥ 6.0m/s2
Cutting head positioning accuracy error ≤ ± 0.15mm
Actual power of the equipment: 4KW.
Compressed air: 0.6PA.
Address: Lunjiao Industrial Zone, Lunjiao town, Shunde District, Foshan City, Guangdong Province
Sales market: China (all provinces have distributors), International (Europe, America, Southeast Asia)
WeChat/WhatsAPP 86 13924817348
We will do our best to provide you with high-quality products and perfect after-sales service!

---
