Product Details
Product Description
Product Description
Brief Introductions:
Type:
| Metal diamond bar
|
Bond:
| Metal bond
|
Application:
| Carbide, glass and ceramic, cast iron, alloy steel, tool steel, die steel, hardened steel copper, aluminum alloy and other abrasive resistant materials
|
Specification:
| Customized
|
Brand Mark:
| Moresuperhard
|
Trade Terms:
| FOB
|
Packages:
| Hard carton
|
Delivery Time:
| 15 workdays by express
|
Introductions of Moresuperhard’s Metal Diamond Honing Bar
More Super hard provides super abrasive diamond and CBN honing stone , honing sticks for honing machines of almost all renowned honing brands (Sunnen, Nagel, Gehring, Belden, AccuCut, Engis, and other types of high-production honing equipment ). Our diamond and CBN honing stones are available for precision bore finishing.
Applications Of Diamond honing stone, CBN honing sticks
Materials of workpiece: carbide, glass and ceramic, cast iron, alloy steel, tool steel, die steel, hardened steel copper, aluminum alloy and other abrasive resistant materials
Applicable area: fine grinding engine pump body, hydraulic cylinder bore, hydraulic pump inner bore, cylinder block, valve, oil cylinder nozzle, the inner surface of the spline bore and cylinder hole and blind hole of other series.
Applicable honing machine: Sunnen, Nagel, Gehring, Belden, AccuCut, Engis, and other types of high-production honing equipment
Model
| Size
| Grit
|
diamond and CBN honing stone
honing stick
| L (mm)
| Width (mm)
| Height (mm)
| 120#～150#
150#～240#
240#~W40
W40~W20
＜W20
|
16-35
| 2, 3, 4, 6
| 2, 3, 4
|
40, 50
| 2, 3, 3.5, 4
| 1, 1.5, 2, 2.5, 3, 3.5, 4
|
60, 70
| 1.5, 2, 3, 3.5, 6, 8
| 2, 2.5, 3, 3.5, 4, 6.5, 7, 8
|
80, 90
| 3, 4, 5, 6, 8, 9, 9.5
| 3, 4, 5, 6, 7, 8, 10
|
100, 120
| 2, 3, 5, 6, 8, 9, 12, 15
| 3, 4, 5, 6, 7, 8, 10, 12, 15
|
140, 150
| 3, 5, 6, 8, 9, 12
| 4, 5, 6, 7, 8, 10, 12
|
200
| 8, 10, 15, 20, 40
| 8, 10, 15, 20
|
Other specifications honing stone can be made according to customers’ requirement. Email: jason@moresuperhard.com
|
Detailed Specifications can be customized!
Guidance of Moresuperhard’s Metal Diamond Honing Bar:
Workpiece material
| Gray iron
|
Honing Machine
| Gehring, Nagel
|
Grinding Tolerance
| <= 80μm
|
Mesh
| Rough D251-D91
|
Semi D76~D30
|
Fine D25~D8
|
Surface finish
| Ra 0.2 – 1 μm
|
Liquid
| Honing oil
|
Bore diameter, roundness, surface roughness and waviness meet the requirements
|
>>
