Lovol Fr18e2-U 1.8ton Mini Hydraulic Digger Excavator 0.04m3

Product Description

product title
FR18E2-U 1.8Ton Mini Hydraulic Excavator with 0.04cbm Capacity
Product Description
Flexible
Tailless, side swing arm, telescopic chassis, split cab, foldable dozer blade, quick-coupling device for various attachments,switchable single/double-direction breaker lines, high flexibility.
Efficient
Large displacement main pump and travel motor, high-torque cycloidal swing motor, large bucket capacity, significantly improving work efficiency.
Imported engine, imported hydraulic components; Boom and arm equipped with anti-burst valves; Internal hydraulic piping;Safety-certified cab; Cast steel structure for boom side shift and boom front fork rear seat, overall reliability and durability.
The cab is the TOPS\FOPS compliant with safety belt, which makes the operation safer. The luxurious seat with armrest and headrest can reduce the operation fatigue dramatically. The lengthened joy stick lever makes operator feel more convenient to operate machine.
One-button start, new intelligent instrument panel, multi-directional adjustable seat for ergonomic functionality, cup holder,phone box, headrest, three-way opening covers. Both operation and maintenance are very convenient and comfortable.
The powerful engine is perfectly matched with outperformed hydraulic system, which could adjust output power according to the demand of working applications that reaches advanced operation performance simultaneously with operation comfort.
Product Parameters

FR18E2-U
Rated Power	kW/rpm	11.5/2400
Bucket Capacity	m³	0.04
Operating Weight	kg	1810
Engine Model	-	3TNV70-PFN
Number of Cylinders	-	3
Max. Torque/Speed	N·m/rpm	48/1600
Displacement	L	0.854
Bucket Digging Force	kN	15.2
Arm Digging Force	kN	8.5
Max. Traction Force	kN	13.5
Max. Walking Speed	km/h	3.7
Min. Walking Speed	km/h	1.9
Rotary Speed	r/min	9
Gradeability	°	30°
Ground Pressure	KPa	29
Max. Main Pump Flow	L/min	2X17.2+10.8
Main Safety Valve Pressure	MPa	21.6
Fuel Tank	L	19
Hydraulic Tank	L	13
Engine Oil	L	1.3-2.8

Detailed Photos
