EB S1E Electric Motorbike EEC L1 NCM Lithium 500W/750W LUYUAN electric vehicle electric bicycle

Product Description

Product Parameters

Model Name	EB S1 E		EEC
Model Number
Motor Type	OKAWA BRUSHLESS WITH GEAR	Derailleru	NO
Motor Power	48V750W	Fork Suspension	DOUBLE SHOULDER SUSPENSION FORK
Controller	48V25A	Wheel/rim size	20"*4.0
Display Board	LCD	Front Chainring	46T WITH 170MM LEG ,PLASTIC COVER
Battery	48V15AH * 2 SETS	Chain	KMC RB CHAIN
Charger	48V 2A	Seat	PU
Throttle	WUXING 130X(LH)	Pedal	JJ YK-13
PAS Sensor	SPEED SENSOR	Frame material	Alloy
Brake	WUXING HYDRALIC DISC BRAKE 180MM	Body Size	1767*745*1074mm
Max Speed	40KM/H	Wheelbase	1155mm
Range	30-160km by different drive mode	Loading	130Kg
Packing size	148*32*83CM	Net Weight	32kg without battery
Container QTY	66pcs/20GP, 168pcs/40HQ	Battery Weight	4.8kg *2

Product Description
EB S1E is a high-speed electric bike with front and rear disc Tektro brakes and an OKAWA-LUYUAN middle drive motor. It has a cool and fantastic design, smooth lines, and strong performance, with a max speed of 40km/h and maximum mileage of 25-100km by different drive modes. With its high-end price, EB S1E is cost-effective and suitable for individuals who enjoy mountain biking and other outdoor sports, allowing them to better explore the wonders of nature and become nature explorers. The electric bike can only be ridden alone. Luyuan, leading the development of core technology of two-wheel electric vehicles and producing products with less trouble and more safety, is committed to providing you with professional electric bicycles and electric scooters! Detailed Photos
Company Profile About Us
Core Technology
What is the advantages of Luyuan 6X liquid cooling motor?
Its inner temperature control system can efficiently control the temperature rise inside motor, which can protect motor from burning, demagnetizing, and component failure caused by overheat. By injecting the cooling liquid, inside motor temperature can drop by 30ºC. It has patented waterproof design with internal air exchange system, which can prevent water entering into motor, thus decreasing the rate of components rusting and short circuit and increasing the motor life cycle. Its motor efficiency can reach 90% and water-proof level is IP67.
Other product
Company Details Company Base
Certificate

Customer&Feedback

Service:Delivery

FAQ
Q1: What kind of service can be provide when become a dealer?
A1: Sales rebate, exhibition support, retailer store support, online/offline training, please ask the sales to get more details.
Q2: Why the new scooters/bikes has some dust and slight traces of use?
A2: Our products need to ride the test function before leaving the factory, clean and clear the number of kilometers before packaging and shipping, to ensure that each car is in line with the quality standards of Luyuan, thus you will find some dust and slight traces.
Q3: Does low ambient temperature affect use?
A3: Low temperature will lead to the reduced endurance and power, for example, the temperature is 25ºC when the battery power output is 100%, when the temperature is 0ºC, the battery continuous discharge power is only about 80% of 25ºC, riding in a low temperature environment, it is recommended to slow down, do not accelerate, speeding, and pay attention to the change of the remaining mileage.
Q4: How to deal with vehicle failure?
A4: Please consult your dealer or sales to help you.
Q5: How to maintain the battery when the vehicle is not used for a period of time?
A5: The vehicle is placed for a long time without use, which can easily lead to over-discharge of the battery. It is recommended that the battery be fully charged for storage after each use. If it is not used for a long time, it needs to be charged once a month, which is conducive to extending the battery life.
Q6: Whether the battery/charger can be disassembled without permission?
A6: The battery/charger can not be disassembled without permission, and the warranty service will be lost after disassembly.

---
