3-Axis Digital Read out Scale (SDS3, SDS6)

Product Description

Digital Read out (SDS3, SDS6)
Digit readout DRO specially for using lathe, milling, boring, grinding machines
The SDS3 DRO is smallest, it is designed for clients to measure the single axes and possesses powful functions.
The SDS6 2V is a Multifunctional 2 axis digital readout. It can adapt the different needs of machining by modifying the system parameters. It has many graphics machining functions, such as: Arc Calculation function, circular equally dividing holes, drilling hole along an oblique line, Angular Surface Processing, Calculation function, Measurement for Taper Function, Digital Filter Function. These functions bring the easiness for the graphics function.
SDS6-3V is multifunctional 3-coordinate numerical display gauge. By different machine tool, this gauge can switch to corresponding function just by changing the parameters. It is provided with many graphic machining functions, including: R-arc function, equal-division function, bevel machining function and diagonal boring function for milling machine; EDM function for spark tester; Tool library and taper measuring function for lathe. With these functions, it can largely reduce the difficulty up graphic machining.

mm/inch Measurement Transformation	Absolute/Relative Transformation
Linearity Error Compensation	Mid-split Function
Zero Adjustment	Absolute Reference Mark
Resolution Setting	Grinding Maching Debouncing Function
Radius/diameter Conversion	RS-232-C Interface(addition)
Power Down Memory	Congruous Ouput(additional)
Take samples for outer I/O
200 Points Auxiliary Zero Position Function			Mathematics calculation (Applicable to milling machine)
Non-volatile memory			Error not linear and Error linear
Mid-split Function			mm/inch Measurement Transformation
PCD circumferential division (Applicable to milling machine and spark tester)		Diagonal boring (Applicable to milling machine)
Involute chamber machining function (Applicable to milling machine)		Anti-dithering function (Applicable to grinding machine)
Bevel machining (Applicable to milling machine)		R-arc function (Applicable to milling machine)
N3 function (Applicable to milling machine)		200-tool library (Applicable to lathe)
Taper measuring function (Applicable to lathe)

---
